Wurth Elektronik Shielded Wirewound Surface Mount Inductor 15 μH ±30 % 3.2 A Idc 1038 Package WE-TPC 744066150

Wurth Elektronik model 744066150 is a shielded wirewound surface mount inductor designed with a ferrite core and rated for 15 μH inductance with a ±30 % tolerance. It supports a maximum DC current of 3.2 A, making it highly suitable for power electronics applications requiring compact and efficient inductors.

The inductor is housed in a 1038 tape and reel packaging style, facilitating ease of placement in automated manufacturing processes. Its magnetic shielding ensures reduced leakage fields, which is critical for minimizing interference in sensitive electronic circuits.

The physical dimensions are precisely engineered with a length of 10 mm, a diameter of 7.4 mm, and a height of 3.8 mm, allowing integration into tightly packed PCB layouts. The construction uses a wirewound technique on a ferrite core, which guarantees stability and reliability under varied operating conditions.

The component operates reliably over a wide temperature range from -40 °C to 125 °C, suitable for demanding industrial and portable applications. It exhibits a maximum DC resistance of 50 milliohms, thereby reducing power dissipation.

The inductor supports a maximum self-resonant frequency of 16 MHz, making it ideal for high-frequency DC/DC converters and embedded systems. Its applications include portable power devices such as PDAs, digital cameras, PCMCIA cards, and displays, as well as embedded PCs and telemetric data collection equipment.

Features a 1038 tape and reel package suitable for automated PCB assembly. Constructed with a ferrite core and wirewound design ensuring low leakage and high reliability. Operates in temperature range from -40°C to 125°C for robust performance.

Provides a maximum DC resistance of 50 mΩ minimizing power loss. Shielding design reduces electromagnetic interference in sensitive circuits. Maximum self-resonant frequency up to 16 MHz for high-frequency applications. Compact dimensions of 10 mm length, 7.4 mm diameter, and 3.8 mm height for space-saving circuit designs.

Suitable for portable power devices, DC/DC converters, embedded PC, mobile data gathering, and telemetric systems. Complies with IPC/JEDEC J-STD-020E, REACH, RoHS, IEC 60286-3:2013, IEC 61249-2-21, JEDEC JS709B standards.

This Wurth Elektronik surface mount inductor is a reliable solution for electronic designs demanding high current capability within a shielded and compact form factor. It meets stringent industrial standards, making it a preferred choice for professional electronics manufacturing and repairs.
