STMicroelectronics Current Sensing Amplifier Single 8-Pin SO-8, 2.7-5.5 V Supply, 5mA, 80dB CMRR TSC2012HYDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.75mm |
| Length | 5mm |
| Model | TSC2012HYDT |
| Mount Type | Surface |
| Series | TSC2012 |
| Maximum Operating Temperature | 150°C |
| Package Type | SO-8 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 5mA |
| GBP - Gain Bandwidth Product | 490kHz |
| CMRR - Common Mode Rejection Ratio | 80dB |
Key Features
- The device operates from 2.7 to 5.5 V supply voltage ensuring flexible power supply options.
- Offers a high common mode rejection ratio (CMRR) of 80 dB for accurate signal processing.
- Has a low supply current of 5 mA to support energy-efficient designs.
- Includes a gain bandwidth product (GBP) of 490 kHz for responsive current sensing.
- Designed for wide operating temperature range from -40°C to 150°C, suitable for automotive applications.
- The package is a standard surface mount SO-8 with 8 pins, compact for PCB layouts.
- Meets automotive standard AEC-Q100, ensuring reliability in harsh environments.
- Features very low offset voltage ±200 μV maximum and a gain error of 0.3% maximum.
Product Description
STMicroelectronics TSC2012HYDT is a precision bidirectional current sensing amplifier available in a compact 8-pin SO-8 surface mount package. It is designed to sense current using a shunt resistor over an extensive common mode voltage range from -20 to +70 V. The device supports supply voltages between 2.7 V and 5.5 V, making it suitable for various industrial and automotive applications requiring efficient and accurate current measurement.
The amplifier delivers a high common mode rejection ratio of 80 dB, which minimizes errors caused by voltage fluctuations. With a supply current of only 5 mA, it suits low power consumption designs. It achieves a gain bandwidth product of 490 kHz for rapid current detection and a maximum offset voltage of ±200 μV, ensuring precise output signals.
The TSC2012HYDT operates reliably across a broad temperature range from -40°C up to 150°C, meeting the rigorous automotive standard AEC-Q100. Its surface mount SO-8 package is compact, facilitating integration into space-constrained PCBs.
Typical applications include industrial current monitoring, automotive systems, power management, and measurement instrumentation. The device's capability to sense very low drop voltages as small as 10 mV full scale reduces measurement error, enhancing system accuracy.
The amplifier supports bidirectional current sensing for a wide current range. The offset drift is limited to 5 μV/°C, providing temperature stability. Surface mount SO-8 package is easy to integrate with automated assembly.
Reliable operation under harsh environmental conditions is ensured by automotive certification. Compact dimensions of 5 mm length and 1.75 mm height allow versatile PCB placement.
This product is ideal for professionals involved in electronics design, automotive electronics, industrial control systems, and power electronics. Explore EnvMart’s extensive collection of semiconductor amplifiers for advanced current sensing solutions.
Explore more products in our Current Sensing Amplifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range of 2.7 V to 5.5 V.
It features a high common mode rejection ratio (CMRR) of 80 dB, which helps in accurate signal processing.
The supply current for this unit is 5 mA, making it suitable for low power consumption designs.
The gain bandwidth product (GBP) of the TSC2012HYDT is 490 kHz, allowing for responsive current sensing.
This model operates over a wide temperature range from -40°C to 150°C, suitable for various applications including automotive.
The dimensions of this current sensing amplifier are 5 mm in length and 1.75 mm in height.
It is packaged in a standard surface mount SO-8 configuration, which is compact for PCB layouts.
This amplifier meets the automotive standard AEC-Q100, ensuring reliability in harsh environments.
This model supports a single channel for current sensing applications.
The maximum offset voltage for this unit is ±200 μV, which contributes to its precision in output signals.
Typical applications include industrial current monitoring, automotive systems, power management, and measurement instrumentation.
The offset drift for the TSC2012HYDT is limited to 5 μV/°C, providing temperature stability for accurate measurements.
