STMicroelectronics Current Sensing Amplifier Single 6-Pin SC-70-6 TSC211IYCT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.1mm |
| Length | 2.2mm |
| Model | TSC211IYCT |
| Mount Type | Surface |
| Series | TSC211 |
| Maximum Operating Temperature | 125°C |
| Package Type | SC-70-6 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 6 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 26V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 5mA |
| GBP - Gain Bandwidth Product | 8kHz |
| CMRR - Common Mode Rejection Ratio | 105dB |
Key Features
- Operates with a supply voltage range between 2.7 V and 26 V.
- Offers a high common mode rejection ratio of 105 dB for accurate measurements.
- Provides a gain bandwidth product of 8 kHz suitable for current sensing.
- Surface mount device with a compact 6-pin SC-70-6 package measuring 2.2 mm by 1.1 mm.
- Designed to meet automotive standard AEC-Q100 with operating temperature range from -40°C to 125°C.
- Consists of a single channel with low quiescent current.
- Features gain error of ±1% maximum, offset drift of 0.1 μV/°C maximum, and gain drift of 20 ppm/°C maximum.
- Ensures zero-drift architecture for high precision current sensing across a wide common mode voltage range from -0.3 to +26 V.
Product Description
STMicroelectronics TSC211IYCT is a highly precise current sensing amplifier featuring a single channel in a compact 6-pin SC-70-6 surface mount package measuring 2.2 mm length and 1.1 mm height.
Designed to sense current through a shunt resistor across a wide range of common mode voltages from -0.3 V up to 26 V regardless of supply voltage, the device supports supply voltages from 2.7 V to 26 V. It provides excellent performance with a common mode rejection ratio of 105 dB and a gain bandwidth product of 8 kHz, ensuring accurate current measurement even in noisy industrial environments.
The TSC211IYCT utilizes a proprietary zero-drift architecture delivering gain error within ±1%, offset drift as low as 0.1 μV/°C, and gain drift limited to 20 ppm/°C. This makes it suitable for industrial, automotive, and telecommunications applications. Its compliance with automotive standard AEC-Q100 allows operation in harsh temperature environments ranging from -40°C to 125°C.
The device is supplied as a surface mount component with a 6-pin SC-70-6 package ideal for space-constrained designs requiring robust and reliable current sensing. Compact 6-pin SC-70-6 surface mount package. Wide supply voltage range from 2.7 V to 26 V.
High common mode voltage sensing capability from -0.3 V to +26 V. Zero-drift architecture with minimal gain error and drift. Automotive AEC-Q100 certified for reliability in harsh conditions. Low quiescent current, suitable for power-sensitive applications.
High precision current sensing for industrial, automotive, and telecom uses. Operating temperature from -40°C up to 125°C.
This current sensing amplifier is ideal for integrating into high-precision current monitoring and measurement circuits in industrial automation, automotive electronics, telecom equipment, and other critical electronic systems demanding accurate and stable current sensing. EnvMart provides this component for engineers and manufacturers seeking robust and compact current sensing solutions.
Explore more products in our Current Sensing Amplifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a supply voltage range between 2.7 V and 26 V.
It offers a high common mode rejection ratio of 105 dB for accurate measurements.
The gain bandwidth product of this unit is 8 kHz, suitable for current sensing applications.
It is designed to operate within a temperature range from -40°C to 125°C, complying with automotive standards.
This current sensing amplifier comes in a compact 6-pin SC-70-6 package measuring 2.2 mm in length and 1.1 mm in height.
It utilizes a zero-drift architecture, ensuring minimal gain error and drift for high precision current sensing.
The gain error for this amplifier is ±1% maximum, ensuring accurate current measurements.
This model has a low quiescent current of 5 mA, making it suitable for power-sensitive applications.
It is suitable for industrial, automotive, and telecommunications applications that require precise current sensing.
The offset drift is as low as 0.1 μV/°C maximum, contributing to its precision.
This amplifier consists of a single channel for current sensing.
It is designed to meet the automotive standard AEC-Q100, ensuring reliability in harsh conditions.
