DiodesZetex N-Channel MOSFET 3.6 A 60 V Enhancement Mode 3-Pin SOT-89 ZXMN6A11ZTA
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.6mm |
| Length | 4.6mm |
| Model | ZXMN6A11ZTA |
| Width | 2.6mm |
| Mount Type | Surface |
| Series | ZXMN6A11Z |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-89 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 3.6A |
| Maximum Drain Source Voltage Vds | 60V |
| Maximum Drain Source Resistance Rds | 180mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 2.6W |
| Typical Gate Charge Qg @ Vgs | 5.7nC |
| Maximum Gate Source Voltage Vgs | -20, +20V |
| Forward Voltage Vf | 850mV |
Key Features
- Designed for surface mount applications with enhanced mode channel.
- Maximum power dissipation of 2.6W for reliable performance.
- Low drain-source resistance of 180mΩ reduces conduction losses.
- Wide operating temperature range from -55°C to 150°C.
- Typical gate charge of 5.7nC ensures efficient switching.
- Compliant with automotive standard AEC-Q101 for quality assurance.
- Compact dimensions of 4.6mm length, 2.6mm width, and 1.6mm height.
- Maximum gate-source voltage rating of ±20V for robust operation.
Product Description
DiodesZetex ZXMN6A11ZTA is a high-quality N-Channel MOSFET designed for diverse electronic and power management applications requiring efficient switching and low conduction losses. Featuring a maximum continuous drain current of 3.6 A and a maximum drain-source voltage of 60 V, this device operates in enhancement mode and offers stable performance in compact SOT-89 surface-mount package with 3 pins.
The MOSFET provides a maximum power dissipation of 2.6W which supports demanding conditions in industrial and automotive environments. With a low drain-source resistance of 180mΩ, it ensures minimal power loss and improved system efficiency especially in switching regulators, power amplifiers, and DC-DC converters.
Designed for reliable operation in a wide temperature range from -55°C to 150°C, the ZXMN6A11ZTA meets the automotive standard AEC-Q101, making it suitable for automotive electronics and harsh environment industrial systems. The gate charge of 5.7nC facilitates rapid switching, optimizing power conversion and control circuits.
Measuring just 4.6mm by 2.6mm by 1.6mm, the small form factor allows compact PCB designs. The device supports gate-source voltages of -20 V to +20 V, ensuring robust gate control under various circuit conditions.
This MOSFET is ideal for use in power supply circuits, industrial electronics, consumer electronic devices, telecommunications, and automotive controls where high efficiency and durability are essential. The package design facilitates easy surface mounting for automated assembly lines.
Designed for surface mount applications with enhanced mode channel. Maximum power dissipation of 2.6W for reliable performance. Low drain-source resistance of 180mΩ reduces conduction losses. Wide operating temperature range: -55°C to 150°C.
Typical gate charge of 5.7nC ensures efficient switching. Compliant with automotive standard AEC-Q101. Compact SOT-89 3-pin package. Robust gate-source voltage rating ±20V. Explore more DiodesZetex MOSFETs and related semiconductor components in the Electronics & Electricals category at EnvMart for enhanced power and signal control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for this model is 3.6 A.
It has a maximum drain-source voltage rating of 60 V.
The maximum power dissipation for this unit is 2.6 W.
This model operates within a temperature range of -55°C to 150°C.
The dimensions of the SOT-89 package are 4.6 mm in length, 2.6 mm in width, and 1.6 mm in height.
The typical gate charge for this model is 5.7 nC.
It features a low drain-source resistance of 180 mΩ.
This model is compliant with the automotive standard AEC-Q101.
The maximum gate-source voltage rating is ±20 V.
This model has an N-channel configuration.
It is designed for surface mount applications.
The SOT-89 package of this MOSFET has 3 pins.
