DiodesZetex 20 V 350 mA Schottky Diode 2-Pin Surface Mount SOD-123 SD103CW-7-F
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.35mm |
| Length | 2.85mm |
| Model | SD103CW-7-F |
| Width | 1.7mm |
| Mount Type | Surface |
| Series | SD103CW |
| Maximum Operating Temperature | 125°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC |
| Maximum Continuous Forward Current If | 350mA |
| Peak Reverse Repetitive Voltage Vrrm | 20V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 1.5A |
| Maximum Forward Voltage Vf | 600mV |
| Peak Reverse Recovery Time trr | 10ns |
Key Features
- Maximum continuous forward current of 350 mA.
- Peak reverse repetitive voltage of 20 V for robust reverse blocking.
- Compliant with automotive standard AEC ensuring durability.
- Low forward voltage drop of 600 mV improving efficiency.
- Peak reverse current is limited to 5 μA for minimal leakage.
- Wide operating temperature range from -65°C to 125°C for diverse environments.
- Fast peak reverse recovery time of 10 ns supports high frequency applications.
- Single diode configuration ideal for rectifier and protection circuits.
Product Description
DiodesZetex SD103CW-7-F is a surface mount Schottky diode designed for electronic and industrial semiconductor use with a maximum forward current of 350 mA and peak reverse voltage rating of 20 V. Its 2-pin SOD-123 package allows easy integration into compact circuit designs, providing efficient rectification with a low forward voltage drop of 600 mV and fast switching speed with a peak reverse recovery time of 10 ns.
The diode operates reliably across a wide temperature range from -65°C to 125°C, meeting stringent automotive standard AEC requirements, which makes it suitable for automotive and harsh environment applications. Its minimal peak reverse current of 5 μA ensures low leakage and higher efficiency in protection and rectifying roles.
This Schottky barrier diode advances typical PN junction diode characteristics by delivering low forward voltage and enhanced thermal stability. It is ideal for use in power supplies, voltage clamping, and fast switching circuits used in industrial, automotive, and manufacturing settings.
With a compact footprint of 2.85 mm length, 1.7 mm width, and 1.35 mm height, it supports space-constrained PCB layouts without sacrificing performance. The single diode configuration streamlines circuit design by providing efficient rectification for DC power conversion and protection tasks.
Maximum continuous forward current of 350 mA. Peak reverse repetitive voltage of 20 V. Automotive standard compliance (AEC). Low forward voltage drop of 600 mV. Fast peak reverse recovery time of 10 ns. Operating temperature range from -65°C to 125°C.
2-pin surface mount SOD-123 package. Low peak reverse current of 5 μA. Compact dimensions 2.85 x 1.7 x 1.35 mm. Single diode configuration.
This product is essential for applications in power supply rectification, automotive electronics, industrial controls, and general semiconductor manufacturing. EnvMart offers an extensive semiconductor category for browsing similar electronic components tailored to your industrial needs.
Explore more products in our Schottky Diodes & Rectifiers category.
