Molex C-Grid III Series Right Angle Through Hole PCB Header, 2 Contact, 2.54 mm Pitch, 1 Row, Shrouded 90136-2202

The Molex 90136-2202 C-Grid III Series Right Angle Through Hole PCB Header is a precision-designed electronic component intended for reliable wire-to-board connections. Featuring a 2 contact count arranged in a single row with a pitch of 2.54 mm, this header is optimized for use in applications demanding robust mechanical and electrical connection.

This PCB header employs a right angle orientation, allowing efficient PCB layouts and facilitating better routing of wires in compact spaces. Its shrouded configuration safeguards the contacts, preventing accidental damage or misalignment during assembly.

Constructed with brass contact material, the contacts are coated with a gold plating to enhance conductivity while offering strong corrosion resistance. The header supports an operating current of up to 3A and can withstand a voltage of up to 350V, making it suitable for moderate power electronic circuits.

Designed to operate within a temperature range from -55°C to 125°C, the component is versatile for use in industrial, electronic manufacturing, and other environments requiring stable performance under varying thermal conditions. The through hole mount type ensures a durable solder joint and mechanical stability.

The tail pin length is 2.9 mm, while the mating pin length measures 6.75 mm, providing secure contact within compatible connectors. This connector system is wire-to-board type, specifically compatible with Molex locking housings to guarantee safe and reliable mating.

Right angle orientation for efficient PCB layouts. Shrouded design offers contact protection. Gold-plated brass contacts for excellent conductivity. Current rating 3A and voltage rating 350V support moderate power circuits.

Temperature range of -55°C to 125°C for industrial applications. Through hole mount type ensures mechanical strength. 2 contacts in a single row with 2.54 mm pitch for standard PCB compatibility. Compatible with locking housings for secure connections.

This Molex PCB Header is ideal for electronics manufacturing, industrial equipment, and laboratory projects that require dependable and durable electronic connectors. Explore our extensive range of PCB connectors at EnvMart for diverse application needs.
