Molex SPOX Series Right Angle Through Hole PCB Header, 10 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 22-05-7105

Molex 22-05-7105 SPOX Series Right Angle Through Hole PCB Header is a precision-engineered electronic component designed for secure wire-to-board connections in demanding industrial and commercial applications. This right angle, shrouded header features 10 contacts arranged in a single row with a 2.5 mm pitch, meeting the exacting requirements of modern PCB designs.

The connector housing is constructed from high-quality nylon, offering excellent durability and electrical insulation. Brass contacts with tin plating provide corrosion resistance and stable electrical performance while supporting currents up to 3A and voltages up to 250V. The tail pin length of 3.5 mm ensures reliable solder termination, making it suitable for through-hole PCB mounting.

Operating temperature ranges from -40°C to 105°C enable usage in automotive, industrial, and telecommunications applications that demand resilience under temperature extremes. The SPOX series connectors incorporate polarization features to prevent incorrect mating and a friction lock mechanism to guarantee secure physical and electrical connectivity during operation.

This connector is part of the Molex SPOX series, known for low profile designs optimizing board space. The 2.5 mm pitch ensures compact yet robust connectivity, making it highly suitable for data communication equipment, medical devices, networking hardware, and consumer electronics requiring dependable wire-to-board interfaces.

The shrouded design protects contacts against accidental damage and short circuits. Right angle orientation supports flexible PCB layout configurations. Durable nylon housing provides mechanical strength and electrical isolation.

Brass contacts plated with tin enable reliable conductivity and long service life. Polarization and friction lock mechanisms secure the connection and prevent mismating. Suitable for automotive, industrial, telecommunications, and consumer electronic applications.

Designed for through-hole solder mounting to PCB for enhanced mechanical stability. Operates over wide temperature range from -40°C to 105°C to meet diverse environments.

This product is manufactured in China and is supplied new. For further detailed technical documentation, 3D models, and footprints, users can refer to Molex resources or compatible PCB design software tools. The Molex SPOX Series ensures a reliable, compact, and efficient wire-to-board connection solution for a variety of industrial and commercial electronics applications.
