DiodesZetex Darlington Transistor PNP 2 A 120 V 3W Surface Mount 4-Pin SOT-223 FZT705TC
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.65mm |
| Length | 6.7mm |
| Model | FZT705TC |
| Mount Type | Surface |
| Series | FZT7053 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-223 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 4 |
| Maximum Continuous Collector Current Ic | 2A |
| Maximum Collector Emitter Voltage Vceo | 120V |
| Number of Elements per Chip | 1 |
| Minimum DC Current Gain hFE | 2000 |
| Transistor Polarity | PNP |
| Maximum Emitter Base Voltage VEBO | 10V |
| Maximum Collector Emitter Saturation Voltage VceSAT | -120V |
| Maximum Collector Base Voltage VCBO | 140V |
| Maximum Collector Cut-off Current | 0.0001mA |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 3W |
| DiodesZetex FZT705TC 1 Darlington Transistor PNP, 2 A 120 V HFE | 2000, 4-Pin SOT-223 |
Key Features
- Durable Darlington transistor with PNP polarity enhances amplifier circuit performance.
- Supports maximum continuous collector current of 2 A for reliable operation.
- Operates at collector emitter voltage of up to 120 V with low saturation voltage.
- Guaranteed minimum DC current gain (hFE) of 2000 for high amplification.
- Compact surface mount SOT-223 package with 4 pins enables easy PCB mounting.
- Wide operating temperature range from -55°C to 150°C suits harsh environments.
- Maximum power dissipation of 3W ensures sustained operation without overheating.
- Meets automotive standard AEC-Q101, suitable for automotive and industrial use.
Product Description
DiodesZetex FZT705TC Darlington Transistor PNP is a high-performance semiconductor device designed for amplification and switching applications. It supports a maximum continuous collector current of 2 amperes and a collector emitter voltage up to 120 volts, making it suitable for various power electronics circuits.
This transistor is housed in a compact 4-pin SOT-223 surface mount package, facilitating easy integration into printed circuit boards with minimal space usage. Its high current gain (minimum hFE of 2000) ensures efficient amplification in audio, power regulation, and automotive electronics applications.
The device features excellent thermal and electrical characteristics with a maximum power dissipation of 3 watts and an operating temperature range from -55°C to 150°C, allowing reliable function in demanding industrial and automotive environments. The low collector cut-off current reduces leakage, enhancing efficiency.
Durable Darlington transistor with PNP polarity enhances amplifier circuit performance. Supports maximum continuous collector current of 2 A for reliable operation. Operates at collector emitter voltage of up to 120 V with low saturation voltage.
Guaranteed minimum DC current gain (hFE) of 2000 for high amplification. Compact surface mount SOT-223 package with 4 pins enables easy PCB mounting. Wide operating temperature range from -55°C to 150°C suits harsh environments.
Maximum power dissipation of 3W ensures sustained operation without overheating. Meets automotive standard AEC-Q101, suitable for automotive and industrial use. Provides low maximum collector cut-off current of 0.0001mA minimizing leakage.
Small form factor with dimensions length 6.7mm and height 1.65mm for space-saving designs.
This Darlington transistor is ideal for industrial, automotive, and power electronic circuits requiring reliable switching and amplification. Its surface mount package and high gain facilitate compact, efficient designs in manufacturing, automation, and embedded systems.
Explore more quality Darlington Transistors and power electronic components on EnvMart for your design and production needs.
