TDK Chassis Mount EMC Filter 12 A 250V AC/DC 50Hz 60 Hz Single Phase Tab Termination B84112G0000B112
Specifications
| Country of Origin | India |
|---|---|
| Brand | TDK |
| Height | 29mm |
| Length | 84.7mm |
| Model | B84112G0000B112 |
| Depth | 52mm |
| Mount Type | Chassis Mount |
| Operating Frequency | 50, 60Hz |
| Series | B84112G |
| Maximum Operating Temperature | 100°C |
| Number Of Stages | 1 |
| Capacitance | 2pF |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 12A |
| Number of Phases | 1 |
| Leakage Current | 369μA |
| Maximum Voltage | 250V ac/dc |
| Inductance | 2mH |
| Standards/Approvals | UL 1283 |
| Termination Style | Tab |
Key Features
- This EMC filter features a compact chassis mount design for easy installation.
- It includes a single stage with high capacitance stability of 2 pF and inductance of 2 mH.
- Operating temperature ranges from -25°C to 100°C for robust industrial use.
- Leakage current is low at 369μA ensuring high efficiency in noise suppression.
- The filter complies with UL 1283 standards for safety and quality assurance.
- Its dimensions are 84.7 mm length, 52 mm depth, and 29 mm height for space-conservative mounting.
- Suitable for industrial electronics, switch-mode power supplies, telecom and data systems, DC applications, and medical equipment.
Product Description
TDK B84112G0000B112 chassis mount EMC filter is designed for single-phase electronic systems requiring effective electromagnetic interference suppression. Rated for a maximum current of 12 A and a maximum voltage of 250 V AC/DC, this filter operates efficiently at 50 Hz and 60 Hz frequencies. Its chassis mount construction with tab termination simplifies installation in varied industrial environments.
The B84112G series features a robust single-stage design with capacitance of 2 pF and inductance of 2 mH, ensuring effective filtering of unwanted noise signals. It supports operating temperatures from -25°C to 100°C, making it suitable for demanding industrial and electronic applications.
The device exhibits a leakage current of only 369μA, which contributes to its energy efficiency and safety during operation. Compliance to UL 1283 standards guarantees reliability and safety, making the filter appropriate for use in sensitive environments such as medical equipment and telecom systems.
Physical dimensions of 84.7 mm length, 52 mm depth, and 29 mm height provide a compact footprint suitable for chassis mounting in constrained spaces. Compact chassis mount design for easy integration. Rated for 12 A current and 250 V AC/DC voltage operation.
Single-phase, single-stage filtering for effective EMI suppression. Wide operating temperature range from -25°C to 100°C. Low leakage current of 369μA enhances efficiency. Compliant with UL 1283 electrical safety standard.
Ideal for industrial electronics, power supplies, telecom, data systems, DC applications, and medical equipment.
This EMC filter is an essential component in ensuring electromagnetic compatibility and noise reduction in advanced industrial and electronic systems. Browse the Electronics & Electricals category at EnvMart for related EMC Filters and power line filter solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this EMC filter is 12 A.
This model operates at a maximum voltage of 250 V AC/DC.
The dimensions of the filter are 84.7 mm in length, 52 mm in depth, and 29 mm in height.
The operating temperature range is from -25°C to 100°C.
It features a tab termination style for easy installation.
The leakage current is low at 369μA, contributing to its efficiency.
It complies with UL 1283 standards for safety and quality assurance.
The inductance of this EMC filter is 2 mH.
This EMC filter is suitable for industrial electronics, switch-mode power supplies, telecom and data systems, DC applications, and medical equipment.
This model has a single-stage design for effective filtering.
It operates efficiently at both 50 Hz and 60 Hz frequencies.
The country of origin for this EMC filter is India.
