| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 1.8mm |
| Model | MMDL301T1G |
| Width | 1.35mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-323 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | Pb-Free, RoHS |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 10mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 200nA |
| Maximum Forward Voltage Vf | 600mV |
onsemi MMDL301T1G is a high-performance Schottky diode designed for surface mounting on printed circuit boards. It supports a continuous forward current of 10 mA and withstands up to 30 V peak reverse repetitive voltage, making it ideal for low voltage rectification and switching applications.
This diode is housed in a SOD-323 package, which is compact and suitable for tight PCB spaces in electronic devices. The low forward voltage drop of 600 mV enhances efficiency and reduces power loss during operation.
Operating optimally within temperatures from -55°C up to 150°C, MMDL301T1G is well suited for industrial, automotive non-automotive, consumer electronics, and power management circuits. Its low leakage current of 200 nA ensures minimal power dissipation when reverse-biased.
Manufactured with compliance to Pb-Free and RoHS standards, this diode meets environmental regulations and supports eco-friendly product design strategies.
Key physical dimensions include a length of 1.8 mm, width of 1.35 mm, and height of 1 mm, allowing integration into compact assemblies. The diode's 2-pin configuration simplifies connection and soldering procedures on double-sided boards.
The diode is optimized for fast switching and minimal forward voltage drop. SOD-323 compact surface mount package reduces PCB footprint. Wide operating temperature range supports various environmental conditions. Low peak reverse current minimizes leakage power losses.
RoHS and Pb-Free compliant for environmental safety. Suitable for industrial electronics, power rectification, and signal switching.
onsemi products deliver reliable performance in semiconductor applications, supporting electronic designs across various sectors. This Schottky diode is an excellent component for engineers seeking efficient, compact, and reliable rectification solutions.
