DiodesZetex Type N-Channel MOSFET 6.4 A, 20 V Enhancement, 3-Pin SOT-23 DMN2041L

DiodesZetex DMN2041L is a Type N-Channel MOSFET transistor designed for high-efficiency electronic applications requiring rapid switching and low power loss. It supports a maximum continuous drain current of 6.4 A with a drain-source voltage limit of 20 V, ideal for moderate power switching circuits.

This device uses enhancement mode operation, providing low on-resistance of 41 milliohms, minimizing conduction losses and heat generation. It comes in a 3-pin SOT-23 surface mount package, which offers space-saving benefits in circuit board design.

With a maximum power dissipation of 780 mW and ability to operate over a wide temperature range from -55°C to 150°C, it is suitable for demanding industrial, automotive, and consumer electronics environments. The MOSFET features a typical gate charge of 15.6 nC, facilitating fast switching speeds for efficient performance.

The maximum gate-source voltage rating of 12 V ensures device safety during transient conditions. It is qualified to the automotive standard AEC-Q101, guaranteeing high reliability especially in vehicle electronics.

Compact dimensions of 3 mm length, 1.4 mm width, and 1.1 mm height make it compatible with modern miniaturized PCB layouts. This MOSFET supports a variety of use cases including power management, motor control, and switching power supplies in industrial and automotive sectors.

The MOSFET operates in enhancement mode for efficient switching. Features a low maximum drain-source resistance of 41 milliohms. Maximum power dissipation is rated at 780 milliwatts. Designed for surface mount applications with a compact SOT-23 package.

Operates reliably in temperatures from -55°C to 150°C. Typical gate charge measured at 15.6 nanocoulombs ensuring fast switching. Maximum gate-source voltage tolerance is 12 V. Includes automotive standard AEC-Q101 qualification for reliability.

Compact dimensions: 3 mm length, 1.4 mm width, and 1.1 mm height.

Suitable for industrial, automotive, and consumer electronics, the DiodesZetex DMN2041L offers reliable performance in power switching applications. Explore more MOSFET products and semiconductor components in EnvMart’s comprehensive electronics catalog.
