Vishay 100 V 3 A Standard Recovery Switching Diode Surface Mount DO-214AA S3B-E3/57T
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 2.42mm |
| Length | 7.11mm |
| Model | S3B-E3/57T |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | S3B |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 3A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 1.15V |
| Peak Reverse Recovery Time trr | 2.5μs |
Key Features
- Rated for a maximum continuous forward current of 3 amperes.
- Peak reverse repetitive voltage of 100 volts ensures high voltage handling capability.
- Features a maximum forward voltage drop of 1.15 volts for efficient switching.
- Compact dimensions of 7.11 mm length, 6.22 mm width, and 2.42 mm height.
- Operating temperature range from -55°C to a maximum of 150°C.
- Switching rectifier type with a peak reverse recovery time of 2.5 microseconds.
- Compliant with automotive standard AEC-Q101, suitable for automotive applications.
- Configured as a single diode with low peak reverse current of 10 microamperes.
Product Description
Vishay S3B-E3/57T is a high-efficiency standard recovery switching diode with a maximum continuous forward current rating of 3 A and peak reverse repetitive voltage of 100 V. It comes in a compact 2-pin DO-214AA surface mount package that ensures compatibility with automated soldering and assembly lines.
This diode is designed for versatile industrial and automotive semiconductor applications where reliable switching speed and thermal stability are crucial. Its maximum forward voltage of 1.15 V and a low peak reverse current make it efficient for use in power rectification and switching circuits.
With an operating temperature range of -55°C to 150°C, it is well-suited for harsh environmental conditions. The peak reverse recovery time of 2.5 µs enables fast switching performance, optimizing power efficiency in electronic systems.
Physical dimensions are compact with a length of 7.11 mm, width of 6.22 mm, and height of 2.42 mm, facilitating use in space-restricted circuits. The product meets automotive AEC-Q101 standards, endorsing its reliability for automotive electronic modules.
The diode supports peak non-repetitive forward surge currents up to 100 A, providing robustness to transient conditions in power circuits. Minimal peak reverse current leakage of 10 µA improves overall circuit performance.
Maximum continuous forward current: 3 A. Peak reverse repetitive voltage: 100 V. Maximum forward voltage: 1.15 V. Peak reverse recovery time: 2.5 µs. Operating temperature range: -55°C to 150°C. Dimensions: 7.11 mm (L) x 6.22 mm (W) x 2.42 mm (H).
Automotive standard AEC-Q101 compliant. Single diode configuration. Peak reverse current: 10 µA. Peak non-repetitive forward surge current: 100 A.
This Vishay standard recovery diode is ideal for industrial, automotive, and power electronics applications requiring reliable switching performance and robust thermal characteristics. It is well-suited for use in load switching, rectification, and protection circuits within HVAC, manufacturing, and automotive control systems.
Explore a wide range of semiconductor products, including high-reliability switching diodes at EnvMart for your next electronic design project.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current rating of this model is 3 A.
This diode has a peak reverse repetitive voltage of 100 V.
The physical dimensions are 7.11 mm in length, 6.22 mm in width, and 2.42 mm in height.
It operates within a temperature range of -55°C to 150°C.
The maximum forward voltage drop is 1.15 V.
The peak reverse recovery time is 2.5 microseconds.
It is configured as a single standard recovery switching diode.
The peak reverse current is 10 microamperes.
It supports peak non-repetitive forward surge currents up to 100 A.
Yes, it is compliant with the automotive standard AEC-Q101.
The diode comes in a DO-214AA surface mount package.
It is suitable for industrial and automotive semiconductor applications, particularly in load switching, rectification, and protection circuits.
