Vishay Bridge Rectifier 800 V 50 A 4-Pin Through Hole DFM Package DF08M-E3/45

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier 800 V 50 A 4-Pin Through Hole DFM Package DF08M-E3/45

Name: Vishay Bridge Rectifier 800 V 50 A 4-Pin Through Hole DFM Package DF08M-E3/45
Brand: Vishay
SKU: 100214
Price: 0.55 USD
Availability: InStock



Category Bridge Rectifier Module Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	3.3mm
Length	8.51mm
Model	DF08M-E3/45
Width	6.5mm
Mount Type	Through Hole
Series	DF
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	DFM
Minimum Operating Temperature	-55°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	800V
Peak Reverse Current Ir	5μA
Peak Non-Repetitive Forward Surge Current Ifsm	50A
Forward Current If	1A
Peak Forward Voltage Vf	1.1V
SIL.BRIDGES 0.9A/800VBrand	NEUTRAL
Vishay Bridge Rectifier, 1A, 800V, 4-PinBrand	Vishay

Key Features

Designed for through-hole PCB mounting with a 4-pin DFM package.
Minium operating temperature of -55°C and maximum operating temperature of 150°C for robust performance.
Single-phase configuration suitable for full-wave rectification applications.
Mature glass passivated chip junction construction ensures high reliability.
Peak forward voltage is 1.1 V ensuring efficient conduction.
High surge current capability up to 50 A supports transient loads.
Compact dimensions (8.51 mm length, 6.5 mm width, 3.3 mm height) optimize board space.
Low peak reverse current of 5 μA enhances efficiency and reduces leakage losses.

Product Description

Vishay DF08M-E3/45 is a high-performance bridge rectifier designed for industrial and electronic applications requiring reliable AC to DC conversion. It supports a peak reverse repetitive voltage of 800 V and a forward current of 1 A with a surge capacity of 50 A, making it suitable for rugged environments.

The device package type is DFM with a through-hole mount, facilitating easy integration into printed circuit boards. Its construction features a miniature glass passivated chip junction that ensures durability and long-term stability under harsh operating temperatures ranging from -55°C to 150°C.

The single-phase, single-configuration bridge rectifier offers efficient full-wave rectification, producing consistent DC output irrespective of AC input polarity. The device features low peak forward voltage drop (1.1 V) and minimal reverse leakage current (5 μA), optimizing power efficiency and thermal performance in industrial electronic circuits.

Compact physical dimensions (length 8.51 mm, width 6.5 mm, height 3.3 mm) contribute to space-saving PCB layouts, while the 4-pin configuration supports automated assembly processes and enhanced surge current handling.

Designed for through-hole PCB mounting with 4-pin DFM package. Operating temperature range from -55°C to 150°C suits diverse industrial environments. Peak forward voltage of 1.1 V ensures efficient conduction. Surge forward current capacity of 50 A protects against transient overloads.

Low peak reverse current of 5 μA reduces leakage and power loss. Glass passivated chip junction design offers improved reliability. Compact dimensions optimize PCB space efficiency.

This bridge rectifier is ideal for use in power supplies, industrial automation systems, and electronic equipment requiring robust rectification solutions. Its reliable performance under varying thermal and electrical stresses makes it suitable for laboratory, manufacturing, and industrial maintenance applications.
