Wurth Elektronik WR-PHD Series Angled Surface PCB Header 4 Contacts 2 mm Pitch 2 Row Unshrouded 621304284521

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-PHD Series Angled Surface PCB Header 4 Contacts 2 mm Pitch 2 Row Unshrouded 621304284521

Name: Wurth Elektronik WR-PHD Series Angled Surface PCB Header 4 Contacts 2 mm Pitch 2 Row Unshrouded 621304284521
Brand: Wurth Elektronik
SKU: 404168
Price: 1.09 USD
Availability: InStock



Category PCB Header Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	200V
Brand	Wurth Elektronik
Orientation	Angled
Current	2A
Mount Type	Surface
Housing Material	Polyamide 9T
Contact Material	Copper Alloy
Series	WR-PHD
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	2mm
Standards/Approvals	RoHS Approval
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Withstanding Voltage	500 V (AC)
Insulator Material	PA9T

Key Features

The PCB header features a 2 mm pitch and dual row configuration.
It supports a current rating of 2A, suitable for low power applications.
Constructed with polyamide 9T housing and copper alloy contacts plated with gold.
Designed for surface mount technology (SMT) and solder termination.
The angled orientation facilitates compact board layouts and ease of assembly.
Operating temperature range from -40°C to 105°C ensures reliable performance under varied conditions.
Meets RoHS compliance standards.

Product Description

Wurth Elektronik 621304284521 is a high-quality WR-PHD series angled surface PCB header specifically designed for robust board-to-board connections in electronic assemblies. This header features 4 gold-plated copper alloy contacts arranged in 2 rows with a 2 mm pitch, providing a reliable electrical interface while optimizing space on the PCB.

The housing is made from durable polyamide 9T material, ensuring excellent insulation and mechanical stability in demanding industrial and commercial electronic applications.

It supports a current capacity of 2A and operates safely within a wide temperature range of -40°C to 105°C, suitable for various environmental conditions encountered in manufacturing, industrial controls, and other electrical systems.

The connector employs surface mount technology (SMT) with solder termination, facilitating automated PCB assembly processes and efficient installation. Its angled orientation and unshrouded design allow flexible mounting options and easy inspection of contacts, making it ideal for compact and accessible PCB layouts.

This component complies with RoHS standards, supporting environmentally conscious production protocols. The PCB header features a 2 mm pitch and dual row configuration. It supports a current rating of 2A, suitable for low power applications.

Constructed with polyamide 9T housing and copper alloy contacts plated with gold. Designed for surface mount technology (SMT) and solder termination. The angled orientation facilitates compact board layouts and ease of assembly.

Operating temperature range from -40°C to 105°C ensures reliable performance under varied conditions. Voltage rating of 200V withstanding voltage up to 500V (AC). Meets RoHS compliance standards.

Commonly used in industrial, manufacturing, electronics prototyping, and repair settings, this header provides reliable signal and power transmission between printed circuit boards.
