Hirose DF13 Series Straight Surface PCB Header, 6 Contacts, 1.25 mm Pitch, 1 Row, Shrouded

Hirose DF13C-6P-1.25V(21) straight surface PCB header is a high-quality, shrouded male connector featuring 6 contacts arranged in a single row with a 1.25 mm pitch. This wire-to-board connector uses a polyamide housing for robust performance and reliable electrical connections in compact footprints.

The header supports a current rating of 1A and voltage up to 150V, making it suitable for a variety of electronic applications. Operating temperature ranges from -35°C to 85°C, allowing use in diverse environments. The copper alloy contacts are tin-plated to ensure low resistance and excellent durability.

The design includes polarization slots to prevent incorrect mating and a friction locking mechanism to secure the connection during use. Surface mount technology mounting with solder terminations allows for precise and reproducible PCB assembly. These connectors also feature PCB mounting bosses for accurate placement and metal fittings for secure attachment to the PCB, especially in SMT versions.

This DF13 series header is ideal for use in portable devices such as digital cameras, LCD displays, digital video recorders, car navigation systems, access control units, and measurement devices. Its miniaturized design supports equipment requiring multiple signals and space-saving configurations.

Compact and space-saving shrouded housing provides protection. Polarization slots and friction locking mechanism prevent misinsertion and secure mating. Polyamide housing material ensures durability in various environments.

Copper alloy, tin-plated contacts offer reliable conductivity. Rated for 1A current and 150V voltage with wide operating temperature range. Surface mount technology and solder termination simplify PCB assembly. Includes PCB mounting bosses and metal fittings for stable installation.

Well-suited for portable electronic devices requiring compact connectors. Explore EnvMart's wide range of high-quality PCB Headers for versatile industrial, electronics manufacturing, and laboratory applications.
