Hirose DF13 Series Straight Surface PCB Header 8 Contacts 1.25 mm Pitch 1 Row Shrouded
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 150V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 1A |
| Model | DF13 |
| Mount Type | Surface |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | DF13 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -35°C |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The compact DF13 series offers miniaturised PCB headers with a space-saving footprint.
- The shrouded housing provides polarization slots to prevent incorrect insertion.
- Gold-plated copper alloy contacts ensure high conductivity and corrosion resistance.
- Surface mount with metal fittings secures the header on the PCB and prevents solder peeling.
- Suitable for use in portable devices such as digital cameras, LCD displays, and access control units.
- The friction locking mechanism guarantees secure mating with compatible connectors.
- Designed to operate reliably between -35°C and 85°C.
Product Description
Hirose DF13C-8P-1.25V(51) Straight Surface PCB Header is a high-quality, compact connector designed for precise wire-to-board applications. It features 8 male contacts in a single row configuration with a 1.25 mm pitch, housed in durable polyamide material with a shrouded design for secure connection and misinsertion prevention.
The DF13 series' compact, miniaturised design allows for dense PCB layouts, ideal for industrial, communication, and consumer electronics applications. The connector boasts gold-plated copper alloy contacts that provide excellent electrical performance and corrosion resistance. It is suitable for surface mount technology (SMT) with metal fittings to ensure solid attachment to the PCB and avoid solder peeling.
This header supports a maximum voltage rating of 150V and a continuous current of 1A, operational across a wide temperature range from -35°C to 85°C. It includes a friction locking mechanism for reliable engagement with mating housings. Polarization slots and scoop-proof housing enhance mating accuracy and durability.
Ideal applications include digital cameras, LCD displays, car navigation systems, access control units, and various measurement devices requiring compact, high-density PCB connectors. The product is made in Japan, evidencing high manufacturing quality.
The compact miniaturised design allows high density in limited PCB space. Shrouded housing with polarization slots prevents misinsertion. Gold-plated copper alloy contacts ensure superior conductivity. Metal fittings provide robust surface mount attachment.
Friction locking mechanism guarantees secure mating connections. Operates reliably between -35°C and 85°C. Supports up to 150V and 1A current capacity. Explore more connectors and components from Hirose at EnvMart for your industrial, electronics, and communication projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 150V.
This header supports a continuous current of 1A.
The pitch size of the contacts in this connector is 1.25 mm.
The contacts are made of gold-plated copper alloy, while the housing is constructed from polyamide.
It operates reliably between -35°C and 85°C.
This model features 8 male contacts.
This connector uses surface mount technology (SMT).
Yes, it includes a friction locking mechanism for secure mating with compatible connectors.
It is suitable for use in portable devices such as digital cameras, LCD displays, and access control units.
The shrouded housing and polarization slots help prevent incorrect insertion.
The contacts in this model are oriented straight.
This product is made in Japan, reflecting high manufacturing quality.
