Samtec MPT Series Straight Through Hole PCB Header 2 Contact 5 mm Pitch 1 Row Shrouded MPT-02-6.30-01-L-V
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 848V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 41.7A |
| Temperature range | -55 → 125 °C |
| Model | MPT-02-6.30-01-L-V |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | MPT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 5mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
| Insulator Material | Black LCP |
| MPT-xx-6.30-01-L-V | Height 6.3 mm, Vertical |
| MPT-xx-01-01-L-RA-SD | Right Angle with Screw Down holes |
Key Features
- The header is shrouded and utilizes a straight orientation for reliable connection.
- Housing is made from durable liquid crystal polymer for high temperature resistance.
- Contact material is copper alloy plated with 0.25 μm gold for optimal conductivity and corrosion resistance.
- Rated for a maximum current of 41.7 A and maximum operating voltage of 848 V.
- Operates reliably in a temperature range of -55°C to 125°C.
- Termination type is soldered through hole for secure PCB mounting.
- Compatible with 1.6 mm thick PCBs and mates with the MPS Series socket.
- Maximum stack height is 14 mm when mated.
Product Description
Samtec MPT-02-6.30-01-L-V is a high-performance straight through hole PCB header designed for robust board-to-board connections in industrial and electronic applications. It features 2 male contacts with a 5 mm pitch arranged in a single row, enclosed in a shrouded housing made from black liquid crystal polymer (LCP) to provide high mechanical strength and thermal stability.
The terminal contacts are constructed from copper alloy with a 0.25 μm gold plating on contact areas for superior electrical conductivity and resistance against corrosion. The PCB tails have a matte tin finish to ensure reliable soldering performance. This header supports a current rating of 41.7 A and voltage rating up to 848 V, making it suitable for power distribution in compact modules.
Its operating temperature range spans from -55°C to 125°C, supporting demanding environments in industrial, manufacturing, and power electronics sectors. The PCB header is intended for use with 1.6 mm thick PCBs and offers a mating stack height of 14 mm with the corresponding MPS series socket. This product is ideal for applications requiring secure and reliable connections with easy assembly and maintenance.
It ensures consistent performance in water treatment, HVAC systems, automation control, and other technical electronics fields. The header is shrouded and uses straight orientation for precise board alignment. Housing's black liquid crystal polymer ensures durability under thermal and mechanical stress.
Gold-plated copper alloy contacts minimize electrical resistance and maximize connection reliability. Through-hole mount and solder termination offers robust mechanical mounting on PCBs. Wide temperature range supports diverse industrial environmental conditions.
Designed to mate with MPS series sockets, making it adaptable for modular designs. Ideal for power connectors in electronic components and industrial automation. Explore the extensive range of Samtec PCB Headers on EnvMart for high-quality electronic connector solutions tailored for varied industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 41.7 A.
This PCB header has a maximum operating voltage of 848 V.
It operates reliably in a temperature range of -55°C to 125°C.
The termination type for this model is soldered through hole, ensuring secure mounting on PCBs.
The housing is made from liquid crystal polymer, while the contacts are constructed from copper alloy with gold plating.
This model features 2 male contacts arranged in a single row.
The pitch of this PCB header is 5 mm.
When mated with the corresponding MPS series socket, the maximum stack height is 14 mm.
Yes, it is compatible with PCBs that are 1.6 mm thick.
The contacts are arranged in a straight orientation for reliable connection.
It is suitable for power distribution in compact modules and various industrial applications, including automation control and HVAC systems.
The country of origin for this PCB header is India.
