Vishay 600 V 60 A General Purpose Rectifier & Schottky Diode 3-Pin TO-247AD 2L VS-E5TX3006THN3
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 10.51mm |
| Length | 29.27mm |
| Model | VS-E5TX3006THN3 |
| Width | 4.65mm |
| Mount Type | Through Hole |
| Series | VS-E5TX |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-247AD 2L |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS and AEC-Q101, JESD 201 Class 2 whisker test |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 60A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 20μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 310A |
| Maximum Forward Voltage Vf | 2.1V |
Key Features
- Designed for high efficiency in soft switched and resonant converters.
- Optimized for high speed operation with hyperfast switching and low conduction losses.
- Maximum continuous forward current of 60 amperes.
- Peak reverse repetitive voltage is 600 volts.
- Operates reliably between -55°C and 175°C junction temperatures.
- AEC-Q101 automotive qualified with JESD 201 class 1A whisker test.
- Features polyimide passivation for enhanced reliability.
- Compact dimensions with length 29.27mm, width 4.65mm, and height 10.51mm.
Product Description
Vishay VS-E5TX3006THN3 is a high-performance general purpose rectifier and Schottky diode designed for demanding industrial and automotive semiconductor applications. It is rated for maximum continuous forward current of 60 A and a peak reverse repetitive voltage of 600 V, making it suitable for power conversion stages requiring high efficiency and reliability.
This device features a three-pin TO-247AD 2L through-hole package designed for stable thermal management and easy PCB mounting. Its hyperfast switching capabilities and optimized quick recovery charge (Qrr) reduce switching losses, which improves overall efficiency, especially in hard switching converters.
The diode operates within a wide temperature range from -55°C up to 175°C junction temperature, ensuring dependable performance under harsh industrial and automotive operating conditions. It has passed the AEC-Q101 automotive standard and JESD 201 class 1A whisker test, making it an ideal choice for electric vehicle (EV) and hybrid electric vehicle (HEV) battery chargers.
Polyimide passivation enhances device reliability and longevity under thermal and electrical stress. With a compact form factor (29.27 mm length, 4.65 mm width, and 10.51 mm height), the VS-E5TX3006THN3 provides a balance of size and power handling capability.
This product is well suited for applications in industrial power supply designs, automotive power electronics, consumer electronics, and renewable energy systems where efficient rectification and fast switching diodes are critical.
Designed for soft switched and resonant converters in industrial and automotive environments. Optimized for high speed LLC output rectification stages of EV/HEV on-board chargers. AEC-Q101 qualified and tested to stringent automotive reliability standards.
High 60 A forward current capability for demanding power applications. Wide temperature operating range to withstand industrial and automotive conditions. Polyimide passivation provides enhanced electrical and mechanical durability.
Compact TO-247AD 2L package suitable for through-hole mounting. Explore our extensive category of discrete Semiconductors and Schottky diodes for efficient power management and circuit design solutions at EnvMart.
