DiodesZetex 1 A NPN Transistor, 80 V, 3-Pin SOT-89, Surface Mount, BCX56TA

DiodesZetex BCX56TA is a general-purpose NPN bipolar transistor designed for surface mounting in SOT-89 package. It can handle a maximum DC collector current of 1 ampere and a collector-emitter voltage of up to 80 volts. This transistor is well-suited for automotive and industrial electronic applications requiring robust and reliable switching or amplification.

The device features a maximum collector-base voltage of 100 volts and a transition frequency of 150 MHz, making it suitable for medium-frequency applications. It offers power dissipation of 1 watt, ensuring thermal stability under load conditions. The transistor has a single configuration with three pins optimized for surface mounting on printed circuit boards.

Operating temperature ranges from -55°C to 150°C, supporting demanding environmental conditions commonly found in automotive and industrial electronics. The transistor’s minimum DC gain (hFE) is 25, providing adequate amplification for control and switching circuits.

Package dimensions are compact, with length 4.6 mm, width 4.25 mm, and height 1.6 mm, designed for efficient PCB layout. It complies with stringent automotive standards including AEC-Q200, AEC-Q101, and AEC-Q100, which attest to its reliability and quality levels required in automotive systems.

Manufactured in China, the BCX56TA transistor is ideal for use in power management, signal amplification, automotive control systems, and other industrial electronic devices requiring stable NPN transistor performance.

The transistor supports a maximum collector base voltage of 100 volts. Maximum transition frequency is rated at 150 MHz. Power dissipation capability is 1 watt for thermal stability. It features 3 pins and a transistor configuration of a single device.

Operating temperature range spans from -55°C to 150°C suitable for automotive applications. NPN polarity ensures compatibility with a wide range of electronic circuits. Current gain minimum hFE is 25 providing sufficient amplification.

Package dimensions include length of 4.6 mm, width 4.25 mm, and height 1.6 mm. Meets automotive standards AEC-Q200, AEC-Q101, and AEC-Q100. Manufactured in China with surface mount technology suitability. Explore more DiodesZetex Bipolar Transistors and other semiconductor components on EnvMart for your industrial and automotive electronics requirements.
