onsemi High Voltage Schottky Diode 100 V 2 A Surface Mount DO-214AC MURA210T3G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 2mm |
| Length | 4.57mm |
| Model | MURA210T3G |
| Width | 2.92mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 2A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | High Voltage |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 50A |
| Maximum Forward Voltage Vf | 940mV |
| Peak Reverse Recovery Time trr | 30ns |
Key Features
- This diode features a DO-214AC package suitable for compact mounting on PCBs.
- It has a peak forward surge current rating of 50 A.
- The maximum forward voltage is 940 mV ensuring efficient conduction.
- The diode operates within a temperature range of -65°C to 175°C, supporting various industrial environments.
- It conforms to the automotive standard AEC-Q101, confirming reliability in automotive applications.
- Peak reverse current is minimal at 50 μA, reducing leakage and power loss.
- Its fast recovery time of 30 ns optimizes switching performance in power circuits.
- Compact dimensions with length 4.57 mm, width 2.92 mm, and height 2 mm allow for easy board integration.
Product Description
onsemi MURA210T3G is a high-voltage Schottky diode housed in a surface mount DO-214AC package designed to handle up to 100 V peak reverse repetitive voltage and 2 A continuous forward current.
This diode offers robust electrical characteristics ideal for power rectification and protection in industrial, automotive, and consumer electronic applications. Its fast switching speed with a peak reverse recovery time of 30 nanoseconds and low forward voltage drop of 940 mV enhance circuit efficiency and reduce thermal losses.
The device withstands a wide temperature range from -65°C to 175°C, ensuring reliable operation in diverse environments including automotive systems meeting the AEC-Q101 standard for quality and performance.
Compact physical dimensions facilitate integration into space-constrained PCBs. Packaging in DO-214AC standard allows automated assembly, improving production efficiency. This diode features a DO-214AC package suitable for compact mounting on PCBs.
It has a peak forward surge current rating of 50 A. The maximum forward voltage is 940 mV ensuring efficient conduction. The diode operates within a temperature range of -65°C to 175°C, supporting various industrial environments.
It conforms to the automotive standard AEC-Q101, confirming reliability in automotive applications. Peak reverse current is minimal at 50 μA, reducing leakage and power loss. Its fast recovery time of 30 ns optimizes switching performance in power circuits.
Compact dimensions with length 4.57 mm, width 2.92 mm, and height 2 mm allow for easy board integration. High voltage and current ratings make it suitable for power rectification and protection circuits. The diode has no specific approvals or additional standards besides AEC-Q101.
Suitable for applications in power supply rectification, automotive electronics, industrial controls, and other demanding environments requiring robust Schottky diode performance. Explore more high-quality semiconductor devices and Schottky diodes at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse voltage rating is 100 V, making it suitable for high-voltage applications.
It has a maximum continuous forward current capacity of 2 A.
The peak forward surge current rating is 50 A, which allows it to handle brief surges effectively.
This model has dimensions of 4.57 mm in length, 2.92 mm in width, and 2 mm in height, facilitating compact PCB integration.
The maximum forward voltage drop is 940 mV, ensuring efficient conduction in circuits.
The diode operates within a temperature range of -65°C to 175°C, suitable for various industrial environments.
The peak reverse recovery time is 30 ns, optimizing its switching performance in power circuits.
Yes, it conforms to the automotive standard AEC-Q101, confirming its reliability in automotive applications.
It is housed in a DO-214AC surface mount package, which is suitable for compact mounting on PCBs.
The peak reverse current is minimal at 50 μA, reducing leakage and power loss in circuits.
This model features a single diode configuration, making it ideal for various rectification applications.
It is suitable for power supply rectification, automotive electronics, and industrial controls, among other demanding environments.
