TDK Film Capacitor 1 nF 500V AC 3 kV DC Through Hole 2 Pin B81123C1102M000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 1 nF 500V AC 3 kV DC Through Hole 2 Pin B81123C1102M000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	10.5mm
Length	18mm
Model	B81123C1102M000
Width	5mm
Mount Type	Through Hole
Series	B81123
Maximum Operating Temperature	110°C
Capacitance	1nF
Standards/Approvals	RoHS, UL
Pin Count	2
Rated AC Voltage	500V ac
Rated DC Voltage	3kV dc
Lead Pitch	15mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200 Rev D
Suppression Class	Y1

Key Features

Rated AC voltage of 500V AC suitable for high-voltage applications.
Rated DC voltage is 3 kV DC ensuring durability and safety.
Lead pitch measures 15mm for compatibility with standard through-hole PCB mounting.
Capacitance is precisely 1 nF for stable electrical performance.
Designed to meet automotive standard AEC-Q200 Rev D for reliability.
Class Y1 suppression type suitable for line-to-ground interference suppression.
High maximum operating temperature up to 110°C for demanding environments.
Complies with RoHS and UL standards ensuring quality and safety.

Product Description

TDK B81123C1102M000 Film Capacitor with 1 nF capacitance is designed for high-voltage applications up to 500V AC and 3 kV DC. This through-hole mounted capacitor features a 2-pin design with a 15mm lead pitch, making it ideal for PCB installations requiring enhanced insulation.

The B81123 series capacitor is suitable for double or reinforced insulation applications classified as Y1 suppression class, providing line-to-ground interference suppression in electronic circuits. Its encapsulation material is self-extinguishing UL94V-0 rated, offering excellent fire resistance and safety compliance.

With adherence to automotive standard AEC-Q200 Rev D, the capacitor ensures reliability in demanding automotive and industrial environments. It operates efficiently at temperatures up to 110°C, providing strong performance even under thermal stress.

Compact dimensions (18mm length, 10.5mm height, and 5mm width) alongside a lead diameter of 0.8mm make this capacitor suitable for tight spaces without compromising electrical integrity. Compliance with RoHS and UL certifications guarantees environmentally friendly construction and adherence to international safety requirements.

Rated for 500V AC operation providing reliable high-voltage performance. 3 kV DC voltage rating for robust insulation capacity. Lead pitch standardized at 15mm for ease of PCB mounting. 1 nF capacitance ensures stable electrical characteristics in various circuits.

Automotive grade quality assures durability and reliability in harsh environments. Class Y1 suppression suitable for safety-critical interference mitigation. High operating temperature tolerance up to 110°C. Self-extinguishing encapsulation for fire safety.

Complies with RoHS and UL for environmental and safety standards.

This TDK film capacitor is ideal for industrial, automotive, and electronic component manufacturing applications requiring high safety standards and reliable performance. Browse more Film Capacitors and electronic components in the Electronics & Electricals category on EnvMart for diverse solutions.
