TDK Film Capacitor 10 nF 500V AC 1 kV DC Through Hole 2 Pin B32671L0103J000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 10 nF 500V AC 1 kV DC Through Hole 2 Pin B32671L0103J000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	12mm
Length	13mm
Model	B32671L0103J000
Width	6mm
Mount Type	Through Hole
Series	B32671L
Maximum Operating Temperature	125°C
Capacitance	10nF
Standards/Approvals	UL, RoHS
Pin Count	2
Rated AC Voltage	500V ac
Rated DC Voltage	1kV dc
Lead Pitch	10mm
Lead Diameter	0.6mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Capacitance of 10 nanofarads ensures precise and stable performance.
Rated for an AC voltage of 500 volts and DC voltage of 1 kilovolt.
Through-hole mounting type with a pin pitch of 10 mm for secure soldering.
Constructed to withstand temperatures up to 125 degrees Celsius.
Compliant with automotive standard AEC-Q200 Rev D and meets UL and RoHS approval standards.
Compact dimensions of 13 mm length, 12 mm height, and 6 mm width optimize PCB space.
Lead diameter of 0.6 mm and pin count of 2 for stable mechanical connections.
Wound metallized polypropylene film capacitor with epoxy resin sealing for durability.

Product Description

TDK B32671L0103J000 Film Capacitor is a high-quality, metallized polypropylene Film Capacitor designed for industrial and electronic applications requiring stable capacitance and high voltage tolerance. This capacitor features a capacitance of 10 nanofarads, rated for 500 volts AC and 1 kilovolt DC, providing versatility for both alternating and direct current environments.

The capacitor uses a through-hole mount with a 10 mm lead pitch, facilitating reliable PCB assembly. Its dimensions (13 mm length, 12 mm height, and 6 mm width) make it suitable for compact circuit designs. The component is rated for operation up to 125°C, aligning with automotive standards AEC-Q200 Rev D and certified under UL and RoHS regulations.

Its construction includes wound capacitor technology with epoxy resin sealing, delivering high pulse withstand capability, peak voltage tolerance, and exceptional stability under high-frequency AC loads and pulse circuits. Available halogen-free versions support environmentally sensitive applications.

Common applications include electronic ballasts, resonant circuits, switched mode power supplies, and other high-frequency or pulse circuit uses, making it suitable for industrial, laboratory, manufacturing, and electronic repair contexts.

Capacitance of 10 nanofarads ensures precise and stable performance. Rated for 500V AC and 1 kV DC voltage applications. Through-hole mounting with 10 mm lead pitch for secure connections. AC-compatible metallized polypropylene film design with epoxy resin sealing.

High pulse current withstand capability and peak voltage tolerance. Operating temperature up to 125°C, compliant with AEC-Q200 Rev D automotive standards. Compact form factor: 13 mm length, 12 mm height, 6 mm width. Halogen-free capacitor versions available on request.

UL and RoHS certified ensuring quality and safety. Ideal for power supplies, ballasts, and high-frequency pulse circuits. Explore more electronic components and capacitors with EnvMart’s extensive catalog for all your industrial and manufacturing needs.
