onsemi N-Channel IGBT 10 A 430 V, 3-Pin TO-252 Surface Mount EcospARK ISL9V2040D3ST
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Model | ISL9V2040D3ST |
| Mount Type | Surface |
| Series | EcoSPARK |
| Energy Rating | 200mJ |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Maximum Continuous Collector Current Ic | 10A |
| Maximum Collector Emitter Voltage Vceo | 430V |
| Maximum Collector Emitter Saturation Voltage VceSAT | 1.9V |
| Channel Type | N |
| Maximum Power Dissipation Pd | 130W |
| Maximum Gate Emitter Voltage VGEO | ±10 V |
Key Features
- Handles a maximum continuous collector current of 10 amperes.
- Supports a maximum collector emitter voltage of 430 volts.
- Maximum power dissipation rated at 130 watts.
- Operates across a temperature range from -40 degrees Celsius to 175 degrees Celsius.
- Features a 3-pin TO-252 package type designed for surface mount applications.
- Maximum gate emitter voltage of plus/minus 10 volts ensuring safe gate operation.
- Low saturation voltage of 1.9 volts for energy-efficient performance.
- Complies with RoHS standards ensuring environmentally safe manufacturing.
Product Description
onsemi ISL9V2040D3ST is an N-Channel Insulated Gate Bipolar Transistor (IGBT) designed for high-efficiency switching applications. Rated for a maximum continuous collector current of 10 amperes and a maximum collector emitter voltage of 430 volts, this component suits various industrial and electronic designs requiring robust power handling.
Housed in a 3-pin TO-252 package, it facilitates surface mounting on PCBs, offering compactness and ease of integration. The device exhibits a maximum power dissipation capacity of 130 watts, allowing it to handle substantial power loads efficiently.
The ISL9V2040D3ST supports operation over a wide temperature range from -40°C to 175°C, making it suitable for demanding environments including industrial, manufacturing, and power electronics sectors. Its maximum gate emitter voltage rating of ±10 V and low collector emitter saturation voltage of 1.9 V contribute to optimized switching performance and energy efficiency.
In compliance with RoHS standards, this transistor ensures environmentally responsible manufacturing practices. Part of the EcoSPARK series, it features a 200 mJ energy rating enhancing its robustness for energy-intensive applications.
High continuous collector current capacity of 10 A. High voltage withstand of 430 V collector emitter voltage. Low saturation voltage enhances efficiency. Wide operating temperature range supports industrial use. Compact TO-252 surface mount packaging.
EcoSPARK series for energy-efficient operation. Meets RoHS compliance for environmental safety. Suitable for power electronics, industrial automation, and motor control applications.
This product is ideal for use in industrial power control, motor drives, and power management circuits. onsemi’s engineering pedigree ensures dependable, quality semiconductor components for a range of applications requiring fast switching and high power ratings.
Explore more electronic components in the IGBT category at EnvMart for reliable, high-performance solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous collector current for this model is 10 amperes.
It supports a maximum collector emitter voltage of 430 volts.
The maximum power dissipation rated at 130 watts allows it to handle substantial power loads efficiently.
It operates across a temperature range from -40 degrees Celsius to 175 degrees Celsius.
It comes in a 3-pin TO-252 package type designed for surface mount applications.
The maximum gate emitter voltage is ±10 volts, ensuring safe gate operation.
The maximum collector emitter saturation voltage is 1.9 volts, contributing to energy-efficient performance.
This model is part of the EcoSPARK series, designed for energy-efficient operation.
It features a 200 mJ energy rating, enhancing its robustness for energy-intensive applications.
Yes, it complies with RoHS standards, ensuring environmentally safe manufacturing practices.
It is ideal for use in industrial power control, motor drives, and power management circuits.
The country of origin for this model is India.
