ABB Protecta XT3N Molded Case Circuit Breaker 3-Pole 250A 36kA Breaking Capacity DIN Rail XT3N

Free Delivery in India | Lowest Global Shipping Charges

ABB Protecta XT3N Molded Case Circuit Breaker 3-Pole 250A 36kA Breaking Capacity DIN Rail XT3N



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	Protecta
Brand	ABB
Height	130mm
Model	XT3N
Depth	70mm
Width	150mm
Mount Type	DIN Rail
Current Rating	250A
Series	XT3N
Breaking Capacity	36kA
Number of Poles	3
Standards/Approvals	CE
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
ABB, Tmax MCCB 200 A, Breaking Capacity 36 kA, DIN Rail MountBrand	ABB

Key Features

Rated current of 250 amperes suitable for industrial and commercial electrical protection.
Breaking capacity of 36 kiloamperes ensuring high fault interruption capability.
Designed for mounting on standard DIN rails for easy integration in panels.
Supports AC voltage rating up to 690 volts and DC voltage rating up to 500 volts.
Compact dimensions with width 150mm, height 130mm, and depth 70mm for space-efficient installations.
Certified with CE standards ensuring compliance and safety.
Part of the Protecta XT3N range known for reliability and performance.
Suitable for photovoltaic (PV) system applications due to high DC voltage insulation up to 1150 Vdc.

Product Description

ABB XT3N Molded Case Circuit Breaker 3-Pole 250A is engineered for robust electrical protection in industrial, manufacturing, and commercial installations. It provides a high breaking capacity of 36 kA, making it ideal for protecting circuits against short circuits and overloads in demanding environments. The breaker features a DIN Rail mount type facilitating quick and secure installation in electrical panels.

This model supports rated AC voltage of up to 690 volts and DC voltage up to 500 volts, suitable for diverse applications including photovoltaic (PV) systems. It complies with IEC 60947-2 and IEC 60947-3 standards, ensuring certified performance and safety compliance.

The compact dimensions of width 150 mm, height 130 mm, and depth 70 mm enable integration into various panel designs without occupying excessive space. The breaker is part of ABB's Protecta XT3N series, widely recognized for its reliability and complete accessory range enabling remote control and customized configurations.

ABB's XT3N series breakers are designed for both AC and DC circuit protection, providing seamless coordination in inverter and parallel switchgear applications, especially in photovoltaic systems with rated insulation voltage up to 1150 Vdc. They accommodate mixed resistive-inductive loads with rated currents up to 1600 A.

Rated current of 250 amperes suitable for heavy-duty electrical distribution. 36 kA breaking capacity for high fault current interruption capabilities. Mount type DIN Rail for convenient panel mounting. Compliance with CE and IEC standards for quality assurance.

Compact form factor with dimensions 150x130x70 mm. High insulation for DC voltage applications up to 1150 Vdc. Designed for photovoltaic system integration and industrial use. Constructed for ease of disassembly and sustainability.

This molded case circuit breaker is a critical component for industrial electrical safety, suitable for use in electrical distribution, manufacturing plants, and renewable energy installations such as solar PV arrays. Its high breaking capacity and versatility in AC and DC applications make it a trusted choice for protecting important electrical assets.
