ABB Tmax XT Molded Case Circuit Breaker 3-Pole 8A Breaking Capacity 65 kA Fixed 1SDA067007R1 XT2N 160 TMD 8A FF

Free Delivery in India | Lowest Global Shipping Charges

ABB Tmax XT Molded Case Circuit Breaker 3-Pole 8A Breaking Capacity 65 kA Fixed 1SDA067007R1 XT2N 160 TMD 8A FF



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	Tmax XT
Brand	ABB
Height	130mm
Model	1SDA067007R1 XT2N 160 TMD 8A FF
Depth	82.5mm
Width	90mm
Mount Type	Fixed
Current Rating	8A
Series	Tmax XT
Terminal type	Fixed
Breaking Capacity	65kA
Number of Poles	3
Standards/Approvals	IEC, CE, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Rated current (In)	8 A In
Rated frequency (f)	50/60 Hz
Rated voltage (Ur)	690 V
Rated impulse withstand voltage (Uimp)	8 kV

Key Features

Designed for 3-pole operation ensuring balanced circuit protection.
Thermal magnetic tripping mechanism for reliable overload and short circuit protection.
Fixed mounting type with front terminals for secure installation.
Rated AC voltage of 690V and DC voltage of 500V to handle various electrical systems.
Compact dimensions of 130mm height, 90mm width, and 82.5mm depth optimize panel space.
Reset lever actuator type for ease of manual operation.
Rated impulse withstand voltage of 8 kV provides enhanced durability against voltage surges.
Complies with IEC, CE, and RoHS standards ensuring quality and safety.

Product Description

ABB 1SDA067007R1 XT2N 160 TMD 8A FF Molded Case Circuit Breaker is a high-performance 3-pole fixed circuit breaker designed for industrial, commercial, and electrical automation use cases. It is engineered to deliver stable and reliable protection for electrical circuits, with an 8A rated current and 65 kA breaking capacity to handle significant fault levels.

The breaker features a thermal magnetic trip unit, which provides effective protection against overloads and short circuits by combining thermal and electromagnetic tripping mechanisms. Its fixed mounting and front terminal design facilitate robust and secure installation in switchboards and distribution panels.

With a rated AC voltage of 690V and DC voltage of 500V, this breaker caters to a broad range of electrical systems and configurations, making it suitable for use in manufacturing plants, water treatment facilities, HVAC systems, and commercial electrical distribution.

Its compact form factor of 130mm height, 90mm width, and 82.5mm depth is optimized for space-saving panel designs. The lever-type reset actuator allows for straightforward manual resetting of the breaker after a trip event.

This MCCB's capability to withstand impulse voltages up to 8 kV ensures durability and resistance against transient voltage spikes, contributing to prolonged operational life. The product complies with international IEC, CE, and RoHS standards, affirming its compliance with strict safety and environmental regulations.

Manufactured in Italy, the ABB Tmax XT series breakers are well-regarded for their reliability and robust construction, making them ideal for industrial automation, electrical distribution, and safety-critical applications.

3-pole fixed mounting breaker with thermal magnetic trip unit. Rated current of 8A supports low to moderate current loads. High breaking capacity of 65 kA for maximum fault clearing. Rated AC voltage 690V and DC voltage 500V for versatile application.

Compact dimensions suited for panel integration. Lever reset actuator ensures easy maintenance. Impulse withstand voltage rating of 8 kV enhances surge protection. Certified to IEC, CE, and RoHS standards. Ideal for industrial, manufacturing, water treatment, and HVAC sectors.

Explore more products in the Molded Case Circuit Breaker category on EnvMart for reliable and certified electrical protection devices.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The breaking capacity of this molded case circuit breaker is 65 kA, allowing it to handle significant fault levels effectively.

This model has a rated current of 8A, suitable for low to moderate current loads in various applications.

It is rated for an AC voltage of 690V and a DC voltage of 500V, making it versatile for different electrical systems.

This unit features a fixed mounting type with front terminals, ensuring secure installation in switchboards and distribution panels.

The dimensions of this circuit breaker are 130mm in height, 90mm in width, and 82.5mm in depth, optimizing space in panel designs.

It utilizes a thermal magnetic tripping mechanism, providing reliable protection against overloads and short circuits.

The rated impulse withstand voltage is 8 kV, which enhances its durability against voltage surges.

This model complies with IEC, CE, and RoHS standards, ensuring it meets strict safety and environmental regulations.

It features a lever-type reset actuator, allowing for straightforward manual resetting after a trip event.

This molded case circuit breaker is suitable for use in industrial, commercial, and electrical automation applications, including manufacturing plants and HVAC systems.

This model is a 3-pole circuit breaker, designed to ensure balanced circuit protection.

This molded case circuit breaker is manufactured in Italy, reflecting quality craftsmanship in its design.
