Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header, 20 Contact, 3 mm Pitch, 2 Row, Shrouded MPC3

Wurth Elektronik MPC3 Series PCB Header MPC3 is a high-quality straight through hole male header connector with a 3.0 mm pitch, 20 contacts arranged in 2 rows, and a shrouded design for robust mechanical retention and proper mating alignment. The housing is made from durable liquid crystal polymer with UL94-V0 black rating, providing resistance to heat and flame.

The contacts are fabricated from copper alloy and plated with tin to ensure excellent electrical conductivity and solderability. Designed for a wire-to-board connector system, this component supports a nominal current of 5 amps and operates up to 250 volts with a temperature tolerance from -40 to 105 degrees Celsius, making it suitable for demanding industrial and electronic uses.

The 3.2 mm tail pin length allows for reliable through hole PCB mounting, and the dual row configuration suits compact board layouts. This part mates specifically with WR-MPC3 dual row female receptacle housings, forming a complete connector solution.

Shrouded male header ensures protection and mating alignment. Liquid crystal polymer housing rated UL94-V0 offers heat resistance. Tin-plated copper alloy contacts provide reliable connectivity. Supports 5A current and 250V voltage for diverse applications.

Wide operating temperature range from -40°C to 105°C. Through hole mounting with 3.2 mm tail pins ensures strong PCB connections. Dual row, 20 contact configuration suits high density PCB layouts.

This Wurth Elektronik WR-MPC3 series PCB header is ideal for use in power electronics, industrial control systems, and communication equipment requiring stable and durable electrical connections. Its combination of materials and design specifications ensures reliable performance in harsh environments.
