Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header, 20 Contacts, 3 mm Pitch, 2 Row, Shrouded MPC3

Wurth Elektronik MPC3 model is part of the WR-MPC3 series of straight through hole PCB headers featuring 20 contacts arranged in 2 rows with a 3 mm pitch. Designed for robust electronic and power connector applications, this male header connector is shrouded and built for reliable wire-to-board connections.

The housing is crafted from UL94-V0 black Liquid Crystal Polymer (LCP) offering flame retardancy and high durability in demanding industrial environments. Contacts made from copper alloy are tin plated, providing reliable conductivity and protection against corrosion. The termination type is solder, with a tail pin length of 3.2 mm optimized for through-hole PCB mounting.

Operating temperature range from -40°C to 105°C enables use in a wide variety of electronic equipment across industrial, manufacturing, and commercial settings. This connector supports a voltage of 250V and a current rating of 5A, making it suitable for moderate power applications where reliable electrical performance is essential.

The dual row, shrouded design ensures secure mating and prevents damage or short circuits during handling or operation. This particular configuration mates with the WR-MPC3 3.0 mm dual row female receptacle housings, enhancing system integration flexibility.

Commonly employed in electronics manufacturing, power supply units, and control systems, the WR-MPC3 series connector supports efficient assembly and dependable long-term operation in demanding industrial environments.

Package includes one Wurth Elektronik WR-MPC3 Series Straight Through Hole PCB Header with 20 contacts and 3 mm row pitch featuring a shrouded two-row configuration. The connector supports a maximum current of 5A for reliable power transmission.

Housing is made from UL94-V0 rated Liquid Crystal Polymer ensuring high temperature resistance. Each contact is made of copper alloy with tin plating for surface durability. The tail pin length is 3.2 mm and designed for through-hole soldering termination.

Operating temperature range spans from -40°C up to 105°C for robust use in various environments. Connector system supports wire-to-board interfacing with male contact gender. This dual row header is shrouded to enhance connection security and prevent accidental shorts.

Voltage rating is 250V suitable for various electronic and power applications. Ideal for PCB designs requiring compact and reliable wire connections with industrial-grade performance.

Available under the Wurth Elektronik brand, these headers provide trusted quality and compliance ensuring performance in electronics and power connector applications. Discover more products in the PCB Headers category at EnvMart to support your design and manufacturing needs.
