Wurth Elektronik WR-MPC3 Series 3.0mm Pitch Straight Through Hole PCB Header, 16 Contact, 2 Row, Shrouded MPC3

Wurth Elektronik MPC3 series straight through hole PCB header MPC3 provides a high-quality wire-to-board connection solution featuring 16 contacts arranged in 2 rows with a 3mm pitch. The connector is designed with a durable liquid crystal polymer housing that meets UL94-V0 flammability rating, ensuring safety and reliability in electronic assemblies. Its tin-plated copper alloy contacts facilitate excellent electrical performance and corrosion resistance.

This connector supports a current rating of 5A and voltage rating of 250V, suitable for multiple industrial and electronic applications that demand robust and stable contact systems. The connector operates effectively within a temperature range from -40°C up to 105°C, making it suitable for environments with temperature variations.

Meant for through hole mounting with solder termination, the MPC3 header ensures secure mechanical and electrical bonds on printed circuit boards. Its straight orientation and shrouded design provide protection against mechanical damage and misalignment during mating with compatible WR-MPC3 female receptacles. The tail pin length is precisely 3.2mm, providing effective soldering performance on PCB pads.

This product finds extensive use in industrial electronics manufacturing, power distribution systems, and embedded board applications where dual row male PCB headers are required. The shrouded feature enhances connector safety and longevity by preventing accidental contact with the pins and improving mounting stability.

Set contains a single PCB header component as per industry's standardized design and manufacturing norms. Constructed with a liquid crystal polymer housing for enhanced durability. Features copper alloy contacts with tin plating for optimal conductivity.

Mount type is through hole with solder termination for secure PCB mounting. Rated for a current of 5 amperes and voltage of 250 volts. Operates reliably between -40°C to 105°C temperature range. Designed as a straight orientation male connector with kinked tail pins of 3.2mm length.

Shrouded connector system enhances protection and connection security. Compatible with WR-MPC3 series dual row female receptacle housings. Explore more Wurth Elektronik PCB Headers and electronic connectors on EnvMart for enhanced industrial and commercial solutions.
