Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 20 Contacts, 4.2 mm Pitch, 2 Row, Shrouded MPC4

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 20 Contacts, 4.2 mm Pitch, 2 Row, Shrouded MPC4

Name: Wurth Elektronik WR-MPC4 Series Straight Through Hole PCB Header, 20 Contacts, 4.2 mm Pitch, 2 Row, Shrouded MPC4
Brand: Wurth Elektronik
SKU: 379310
Price: 2.04 USD
Availability: InStock



Category PCB Headers Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	600V
Brand	Wurth Elektronik
Orientation	Straight
Current	69A
Model	MPC4
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	WR-MPC4
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	4.2mm
Contact Plating	Tin
Number of Contacts	20
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	3.5mm

Key Features

Features 20 male contacts arranged in 2 rows with a 4.2 mm pitch.
Constructed with a durable polyamide housing offering heat resistance up to 105°C.
Compatible with WR-MPC4 series female dual row plug-style receptacle housings.
Contacts are made from copper alloy with tin plating to ensure optimal conductivity.
Designed for through hole mounting on PCB with solder tail termination and 3.5 mm tail pin length.
Rated for 69A current carrying capacity and operation up to 600V.
Shrouded design enhances connector protection and alignment reliability.
Operates reliably in temperature range from -40°C to 105°C.

Product Description

Wurth Elektronik MPC4 series straight through hole PCB header, model MPC4, provides a high-performance wire-to-board connection solution with 20 male contacts arranged in 2 rows at 4.2 mm pitch. The shrouded dual-row design ensures alignment and protection of contacts during mating, suitable for demanding electronic assembly tasks.

The housing is made from UL94-V0 polyamide (nylon 66) material which guarantees high mechanical strength and heat resistance up to 105°C. Copper alloy contacts with tin plating ensure excellent electrical conductivity and corrosion resistance for long-term reliable operation.

This PCB header is rated for a maximum current of 69A and can withstand operating voltages up to 600V, making it suitable for power applications. The solder tail termination with a 3.5 mm pin length allows secure and stable through-hole mounting on printed circuit boards.

Engineered for industrial, laboratory, electronic manufacturing, and power distribution applications, this connector meets demanding operational and environmental requirements ranging from -40°C minimum to maximum 105°C operating temperature.

A compatible option for use with WR-MPC4 female dual row plug style receptacle housings, these connectors facilitate flexible, secure wire-to-board interconnections. 20 male contacts in 2 rows with 4.2 mm pitch. Polyamide housing with UL94-V0 rating.

Copper alloy contacts with tin plating. Through hole mount type with solder tail termination. 3.5 mm tail pin length. Rated current 69A and voltage 600V. Minimum operating temperature -40°C. Maximum operating temperature 105°C.

Shrouded connector system for protection. Made in China.

This Wurth Elektronik MPC4 series PCB header is ideal for electronics manufacturing, power connectors, and PCB assembly applications where reliable, high current, and secure connections are essential.
