Samtec TSW Series Straight Through Hole Pin Header 28 Contact 2.54 mm Pitch 2 Row Unshrouded TSW-114-07-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 7.6A |
| Model | TSW-114-07-L-D |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 28 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 2.54mm |
| Mating Pin Length | 5.84mm |
Key Features
- Featuring a glass filled polyester housing for durability and insulation.
- Contact material is phosphor bronze with gold plating for reliable electrical performance.
- Unshrouded design for ease of access to pins.
- Operates at voltages up to 550V and currents up to 7.6A.
- Suitable for through hole mount applications with solder termination type.
- Designed to function within a temperature range of -55°C to 125°C.
- Contact gender is male with mating pin length of 5.84 mm and tail pin length of 2.54 mm.
- Compact 2 row, 28 contact configuration for high-density PCB applications.
Product Description
Samtec TSW-114-07-L-D is a high-quality straight through hole pin header designed for PCB board-to-board and wire-to-board connections. Featuring 28 male contacts arranged in 2 rows with a standard 2.54 mm pitch, this pin header ensures stable and efficient electrical connectivity for a variety of industrial and electronic applications.
The housing is constructed from black glass filled polyester, providing excellent mechanical strength and electrical insulation. The contacts are made of phosphor bronze and plated with gold, guaranteeing low contact resistance and corrosion resistance for long-term reliability.
Rated for voltages up to 550V and currents up to 7.6A, this pin header is suitable for demanding operating conditions. It supports through hole mounting with solder termination, making it compatible with standard PCB assembly processes.
Operating temperature ranges from -55°C to 125°C, making it robust in harsh environments. The unshrouded design allows easy access for mating connectors and testing, while the male contact gender and specified mating and tail pin lengths (5.84 mm and 2.54 mm respectively) provide precise mechanical and electrical fitment.
Glass filled polyester housing for mechanical durability. Phosphor bronze contacts with gold plating for enhanced conductivity. Through hole mounting for secure PCB integration. Unshrouded straight orientation for versatile connection options.
High voltage and current ratings suitable for industrial use. Wide operating temperature range supports diverse environments. Standard 2.54 mm pitch ensures compatibility with common PCB layouts. Compact 2 row configuration for efficient space utilization.
Male contact gender ensures compatibility with corresponding female connectors.
Widely used in electronics manufacturing, industrial automation, telecommunications, and power systems, the Samtec TSW-114-07-L-D pin header supports reliable and robust interconnections. This product is ideal for engineers and technicians requiring dependable connector solutions in high-density PCB assemblies.
Explore more high-quality electronic components and connectors in the PCB Headers category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum voltage rating for this model is 550V.
This pin header can handle currents up to 7.6A.
The contact pitch size is 2.54 mm.
The housing is made from glass filled polyester, while the contacts are constructed from phosphor bronze with gold plating.
It operates within a temperature range of -55°C to 125°C.
This pin header features 28 contacts arranged in 2 rows.
It uses a solder termination type for secure mounting.
Yes, it is designed for through hole mounting applications.
The contact gender is male, allowing it to mate with corresponding female connectors.
The mating pin length is 5.84 mm and the tail pin length is 2.54 mm.
It is suitable for board-to-board and wire-to-board connections in various industrial and electronic applications.
The country of origin for this model is India.
