Vishay Bridge Rectifier 400 V 55 A 4-Pin Single Through Hole D-46 Package VS-KBPC104
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 6.35mm |
| Length | 16.7mm |
| Model | VS-KBPC104 |
| Width | 16.7mm |
| Mount Type | Through Hole |
| Series | VS-KBPC1 |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | D-46 |
| Minimum Operating Temperature | -40°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Peak Reverse Current Ir | 10μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 55A |
| Forward Current If | 3A |
| Peak Forward Voltage Vf | 1.1V |
| Vishay Bridge Rectifier, 200 V 55 A, 4-Pin SingleBrand | Vishay |
Key Features
- Supports peak repetitive reverse voltage up to 400 V.
- Forward current rating of 3 A with a peak non-repetitive surge current of 55 A.
- Operates reliably between -40°C to 150°C temperature range.
- Compact D-46 package with dimensions 16.7 mm length, 16.7 mm width, and 6.35 mm height.
- Features low peak forward voltage of 1.1 V and minimal peak reverse current of 10 μA.
- Single-phase configuration suitable for printed circuit board and chassis mounting.
- Designed for high reliability and thermal performance in industrial electronic applications.
Product Description
Vishay VS-KBPC104 Bridge Rectifier is a reliable semiconductor component designed to convert alternating current (AC) into direct current (DC) through full-wave rectification. It features a 4-pin single diode bridge configuration in a compact D-46 through-hole package, ensuring easy integration onto printed circuit boards or chassis mounting systems.
This bridge rectifier supports a peak repetitive reverse voltage of 400 V and a forward current rating of 3 A. It can sustain a peak non-repetitive forward surge current up to 55 A, making it suitable for transient load conditions. The device operates efficiently within an ambient temperature range from -40°C to 150°C, ensuring durability under varied environmental conditions.
With low peak forward voltage of 1.1 V and minimal leakage current (peak reverse current of 10 μA), it offers energy-efficient performance. The compact dimensions of 16.7 mm length, 16.7 mm width, and 6.35 mm height facilitate space-saving designs in electronic power and connector applications.
The Vishay VS-KBPC104 series provides high reliability and optimal thermal performance, ideal for power semiconductor applications in industrial systems, automotive electronics, telecommunications, and power supplies.
Supports peak repetitive reverse voltage up to 400 V. Forward current rating of 3 A with a peak non-repetitive surge current of 55 A. Operates reliably between -40°C to 150°C temperature range. Compact D-46 package with dimensions 16.7 mm length, 16.7 mm width, and 6.35 mm height.
Features low peak forward voltage of 1.1 V and minimal peak reverse current of 10 μA. Single-phase configuration suitable for printed circuit board and chassis mounting. Designed for high reliability and thermal performance in industrial electronic applications.
This bridge rectifier is widely used in manufacturing, industrial machinery, HVAC, power supply units, and laboratory equipment where stable DC output from AC input is essential. It contributes to effective power management and electrical signal integrity in critical electronic circuits.
Explore similar Vishay semiconductor products and other Bridge Rectifiers in the Electronics & Electricals category at EnvMart for advanced circuit solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum peak repetitive reverse voltage for this model is 400 V.
The forward current rating of this bridge rectifier is 3 A.
It can sustain a peak non-repetitive forward surge current of up to 55 A.
It operates reliably between -40°C to 150°C.
The dimensions of the D-46 package are 16.7 mm in length, 16.7 mm in width, and 6.35 mm in height.
The peak forward voltage is 1.1 V.
The peak reverse current is minimal at 10 μA.
This bridge rectifier has a pin count of 4.
It supports through-hole mounting, suitable for printed circuit boards and chassis.
The configuration of this model is single-phase.
It is widely used in manufacturing, industrial machinery, HVAC, power supply units, and laboratory equipment.
The country of origin for this bridge rectifier is India.
