DiodesZetex Schmitt Trigger Input Inverter 6 Elements 14-Pin TSSOP 4.5V to 5.5V 74HCT14T14-13

DiodesZetex 74HCT14T14-13 is a high-speed CMOS logic inverter integrated circuit featuring Schmitt Trigger inputs. It contains 6 independent inverter elements in a 14-pin Thin Shrink Small Outline Package (TSSOP), designed for surface mount applications where space efficiency is required. The device is optimized for low power consumption and high noise immunity due to Schmitt Trigger action at the inputs.

This inverter IC operates reliably over a voltage supply range from 4.5V to 5.5V, making it suitable for 5V logic level systems. It maintains a maximum propagation delay of 51 nanoseconds at typical load conditions ensuring high-speed switching capabilities.

The output stage uses a push-pull type configuration, supporting maximum output currents of 4mA sourcing and -4mA sinking. It belongs to the HCT logic family and is pin-compatible with standard low power Schottky TTL devices, facilitating straightforward replacement and upgrades in existing designs.

Its thermal operating range from -40°C to 125°C qualifies the component for industrial environments and demanding applications. The compact TSSOP package with dimensions of approximately 5.1mm (length), 4.5mm (width), and 1.05mm (height) aids in the design of dense circuit boards.

The device complies with high ESD protection standards, exceeding 200V (Machine Model), 2000V (Human Body Model), and 1000V (Charged Device Model) levels, making it robust against electrostatic discharges during handling and operation.

This inverter IC is typically employed in electronic control systems, signal conditioning circuits, industrial automation, and other semiconductor applications requiring reliable logic inversion and noise immunity.

Operates within a 4.5V to 5.5V supply voltage range ensuring compatibility with common logic levels. Includes 6 Schmitt Trigger input inverter elements in a single 14-pin TSSOP surface mount package. Push-pull output type designed for balanced drive capabilities.

Industrial operating temperature range from -40°C to 125°C suitable for harsh environments. Compact dimensions allow for space-saving PCB layouts. Pin compatible with Low Power Schottky TTL to aid in system upgrades. Enhanced ESD protection exceeding standard industry requirements.
