| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 2.9mm |
| Model | SN74AHC1G04DBVR |
| Width | 1.6mm |
| Mount Type | Surface |
| Series | SN74AHC1G04 |
| Input Type | Schmitt Trigger |
| Maximum Operating Temperature | 85°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | AHC |
| Logic Function | Inverter |
| Minimum Supply Voltage | 2V |
| Maximum High Level Output Current | -8mA |
| Maximum Propagation Delay Time @ CL | 7ns |
| Maximum Low Level Output Current | 8mA |
Texas Instruments SN74AHC1G04DBVR is a high-speed single inverter gate logic IC designed for advanced CMOS technology applications. It is housed in a small 5-pin SOT-23 surface-mount package, enabling integration into compact electronic circuits. The device is optimized for operation with supply voltages from 2 V to 5.5 V and offers fast switching with a maximum propagation delay time of 7 ns, making it suitable for digital signal processing and timing applications.
This inverter includes a Schmitt trigger input for enhanced noise immunity and signal conditioning. The device supports output currents up to ±8 mA at 5 V, allowing it to drive a variety of loads effectively. Its operating temperature range of -40°C to 85°C ensures reliable performance under harsh environmental conditions.
The compact size with a length of 2.9 mm, width of 1.6 mm, and height of 1.15 mm facilitates integration in densely populated printed circuit boards. The SN74AHC series is known for low power consumption and industrial-grade reliability, making it a versatile component for embedded system designs, industrial automation, and consumer electronics.
This product does not carry automotive standards certification but meets general industrial criteria. It is suitable for applications in signal inversion, buffering, switching circuits, and logic functions within semiconductor device assemblies.
This IC operates on a 2-5.5 V power supply margin. Maximum propagation delay time of 7 ns facilitates high-speed logic operations. Output drive capability reaches ±8 mA, suitable for moderate load driving. Survives operating temperature extremes from -40°C to 85°C for industrial reliability.
Surface mount package (SOT-23) allows space-efficient PCB design. Single gate per chip simplifies design and reduces component count. Low typical current consumption improves power efficiency and thermal performance. Compatible with a variety of digital circuits needing Schmitt trigger inputs.
