onsemi Inverter Logic IC 6 Elements 14-Pin SOIC MC74AC04DR2G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Inverter Logic IC 6 Elements 14-Pin SOIC MC74AC04DR2G

Name: onsemi Inverter Logic IC 6 Elements 14-Pin SOIC MC74AC04DR2G
Brand: onsemi
SKU: 374340
Price: 0.23 USD
Availability: InStock



Category Inverter ICs Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	8.75mm
Model	MC74AC04DR2G
Width	4mm
Mount Type	Surface
Output type	Single Ended
Series	MC74AC04
Input Type	Single Ended
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Pin Count	14
Number of Elements per Chip	6
Maximum Supply Voltage	6V
Logic Family	74AC
Logic Function	Inverter
Minimum Supply Voltage	2V
Maximum High Level Output Current	-24mA
Maximum Propagation Delay Time @ CL	10ns
Maximum Low Level Output Current	24mA

Key Features

Logic function is inverter with single-ended input and output.
Contains 6 inverter elements per chip.
Operating voltage ranges from 2V to a maximum of 6V supply voltage.
Maximum propagation delay time at CL is 10 nanoseconds.
Maximum operating temperature ranges from -40°C to 85°C.
Maximum high-level output current is -24mA and maximum low-level output current is 24mA.
Logic family is 74AC with no Schmitt Trigger input functionality.
No automotive standard compliance but built under MC74AC04 series.

Product Description

onsemi MC74AC04DR2G is a high-performance inverter logic IC designed for industrial and electronic applications requiring efficient signal inversion. This component features 6 inverters per chip implemented in a compact 14-pin SOIC surface mount package, measuring 8.75mm in length, 4mm in width, and 1.5mm in height.

The IC operates with a minimum supply voltage of 2V and a maximum supply voltage of 6V, supporting logic family 74AC technology. It offers fast switching with a maximum propagation delay of 10 nanoseconds, enabling reliable performance within advanced electronic and industrial circuits.

Operating temperature ranges from -40°C to +85°C ensure robust performance in harsh industrial environments. The maximum output currents are -24mA for high-level output and 24mA for low-level output, suitable for driving various logic components. The package is surface mount (SOIC), facilitating easy integration on printed circuit boards for automated manufacturing processes.

This inverter IC does not include Schmitt Trigger input functionality and conforms to the MC74AC04 series. It lacks specific automotive approvals but meets general standards for semiconductor devices used in electronic components, power connectors, and logic ICs.

Efficient inverter logic function with 6 elements per chip. Compact 14-pin SOIC package for surface mounting. Wide operating voltage range from 2V to 6V. Fast maximum propagation delay of 10 nanoseconds. Robust operating temperature range from -40°C to 85°C.

Consistent output current specifications for high and low levels. Suitable for industrial, electronics manufacturing, and circuit design applications.

This product is ideal for applications in industrial electronics, manufacturing automation, power connectors, semiconductor circuits, and other laboratory and commercial electrical uses. The MC74AC04DR2G inverter IC provides reliable performance and versatility for a wide range of industrial and electronic needs.

Explore more semiconductor and logic IC products at EnvMart for your design and manufacturing requirements.

Explore more products in our Inverter ICs category.
