onsemi Schmitt Trigger Input Inverter 6 Elements 14-Pin SOIC Surface Mount 3-18V 250ns Propagation Delay MC14106BDR2G
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.5mm |
| Length | 8.75mm |
| Model | MC14106BDR2G |
| Width | 4mm |
| Mount Type | Surface |
| Output type | Single Ended |
| Series | MC14106B |
| Input Type | Schmitt Trigger |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -55°C |
| Pin Count | 14 |
| Number of Elements per Chip | 6 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 18V |
| Logic Family | 4000 |
| Logic Function | Inverter |
| Minimum Supply Voltage | 3V |
| Maximum High Level Output Current | -4.2mA |
| Maximum Propagation Delay Time @ CL | 250ns |
| Maximum Low Level Output Current | 4.2mA |
| Wide operating voltage range | 3 to 18V |
Key Features
- Device belongs to the 4000 CMOS logic family with Schmitt Trigger input.
- Contains 6 inverter elements per chip with single-ended output.
- Maximum propagation delay time is 250 nanoseconds at capacitive load.
- Maximum output current is ±4.2mA for high and low levels respectively.
- Wide operating temperature range from -55°C to 125°C with AEC-Q100 automotive standard compliance.
- Suitable for surface mount applications.
- Wide supply voltage range from 3V minimum to 18V maximum.
Product Description
onsemi MC14106BDR2G is a Schmitt Trigger input inverter designed for reliable logic level inversion in industrial, automotive, and electronic applications. It features 6 inverter elements per chip with single-ended outputs optimized for 4000 series CMOS logic circuits, ensuring wide compatibility and stability.
The device supports a broad operating voltage range from 3 volts to 18 volts, accommodating various power supply conditions. It delivers a maximum propagation delay of 250 nanoseconds at a given capacitive load, enabling timely signal processing in control and logic automation systems.
With a maximum output current of ±4.2 milliamps, the inverter maintains signal integrity for driving downstream logic circuits. The wide operating temperature range from -55°C to 125°C and compliance with the AEC-Q100 automotive standard make this chip ideal for demanding environments including automotive electronics and industrial controls.
The package is a compact 14-pin SOIC surface mount type with physical dimensions of 8.75 mm length, 4 mm width, and 1.5 mm height, facilitating easy PCB layout and high-density mounting.
This inverter is widely used in semiconductor, industrial automation, and automotive sectors where Schmitt Trigger input noise immunity is essential. Typical applications include signal conditioning, waveform shaping, and digital logic interfacing.
Device conforms to 4000 CMOS logic family specifications. The Schmitt Trigger input improves noise margin and signal cleanliness. Surface mount SOIC package allows automated assembly and compact designs. The inverter operates efficiently across a wide supply voltage and temperature range.
Automotive-grade AEC-Q100 certification confirms reliability under harsh conditions. Industry-standard pin count and form factor ensure design compatibility. The inverter supports industrial, automotive, and general electronics use cases.
Explore the comprehensive line of onsemi semiconductor logic ICs and inverters available for advanced industrial and automotive applications on EnvMart.
Explore more products in our Inverter ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 18V.
It has a maximum propagation delay time of 250 nanoseconds at a given capacitive load.
The operating temperature range is from -55°C to 125°C.
This chip contains 6 inverter elements per chip with single-ended outputs.
It uses a Schmitt Trigger input type, which improves noise margin and signal cleanliness.
The package dimensions are 8.75 mm in length, 4 mm in width, and 1.5 mm in height.
The maximum output current is ±4.2 mA for high and low levels respectively.
This inverter complies with the AEC-Q100 automotive standard.
It belongs to the 4000 CMOS logic family.
The mount type for this model is surface mount.
It is suitable for industrial, automotive, and general electronics applications, particularly where Schmitt Trigger input noise immunity is essential.
The input type is Schmitt Trigger, which enhances noise immunity and signal integrity.
