Vishay 45 V 6 A Schottky Barrier Rectifier Surface Mount TO-252 Package V6PWL45HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V6PWL45HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 6A |
| Peak Reverse Repetitive Voltage Vrrm | 45V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100A |
| Maximum Forward Voltage Vf | 0.38V |
Key Features
- Constructed using Trench MOS Barrier Schottky technology for high efficiency operation.
- Suitable for low voltage, high frequency DC/DC converters and freewheeling diode applications.
- Features very low forward voltage drop of 0.38 V reducing power losses.
- Designed for automated placement with a low profile of approximately 1.3 mm height.
- Wide operating temperature range from -40°C to 175°C for robust performance.
- Peak non-repetitive forward surge current of 100 A ensures transient capability.
- Meets RoHS compliance and automotive standard AEC-Q101 for quality assurance.
- Packaged in TO-252 (DPAK) for effective surface mounting.
Product Description
Vishay V6PWL45HM3/I Schottky Barrier Rectifier is a high current density surface mount rectifier designed for use in demanding industrial, automotive, and electronic applications. Featuring a 45 V peak reverse voltage rating and a continuous forward current of 6 A, this device offers excellent efficiency with a low forward voltage drop of 0.38 V, minimizing power dissipation.
Manufactured using advanced Trench MOS Barrier Schottky technology, the device provides very low profile construction with a typical height of 1.3 mm, making it ideal for automated PCB assembly and space-constrained designs.
This rectifier is suited for various applications including low voltage high frequency DC/DC converters, polarity protection, and as freewheeling diodes in power management systems. It withstands harsh operating environments with a temperature range from -40°C up to 175°C, and has a robust peak non-repetitive forward surge current of 100 A for reliable transient handling.
The component complies with RoHS directives and meets automotive standard AEC-Q101, affirming its suitability for automotive electronic systems and other critical applications. Packaged in a TO-252 (DPAK) surface mount package, this rectifier ensures effective thermal management and ease of assembly on modern electronic boards.
Trench MOS Barrier Schottky technology for low power losses. High efficiency operation with low forward voltage drop. Compact surface mount package TO-252 for automated assembly. Wide temperature range supports diverse operating environments.
Compliant with automotive and environmental standards. This Vishay Schottky Barrier Rectifier is an essential component for electronic circuit designers targeting energy-efficient and high-reliability power solutions. Explore more Vishay semiconductor products and related electronic components at EnvMart to fulfill all your industrial and manufacturing requirements.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay V6PWL45HM3/I is 6 A.
This model has a peak reverse repetitive voltage rating of 45 V.
The maximum forward voltage drop for this device is 0.38 V.
It operates within a temperature range of -40°C to 175°C.
The Vishay V6PWL45HM3/I is packaged in a TO-252 (DPAK) surface mount package.
The peak non-repetitive forward surge current rating is 100 A.
Yes, it meets RoHS compliance and the automotive standard AEC-Q101.
This rectifier uses a single diode configuration.
It is constructed using Trench MOS Barrier Schottky technology for high efficiency operation.
This rectifier is suitable for low voltage, high frequency DC/DC converters, polarity protection, and as freewheeling diodes in power management systems.
The height of this model is approximately 1.3 mm, making it suitable for automated placement.
The Vishay V6PWL45HM3/I is manufactured in India.
