Vishay 120 V 10 A Schottky Barrier Rectifier Surface Mount TO-252 Package V10PWM12HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Model | V10PWM12HM3/I |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Maximum Continuous Forward Current If | 10A |
| Peak Reverse Repetitive Voltage Vrrm | 120V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Non-Repetitive Forward Surge Current Ifsm | 180A |
| Maximum Forward Voltage Vf | 0.62V |
Key Features
- Equipped with trench MOS barrier technology for high efficiency.
- Low forward voltage drop of 0.62 V to minimize power losses.
- Supports peak forward surge current up to 180 A.
- Operating temperature range from -65°C to 150°C for reliability.
- Compact low-profile design with typical height of 1.3 mm.
- Suitable for high-frequency DC/DC converters and polarity protection.
- Meets RoHS compliance and automotive qualified base part available.
- Designed for automated placement in surface-mount assembly processes.
Product Description
Vishay V10PWM12HM3/I is a high current density Schottky barrier rectifier designed for efficient performance in low voltage, high frequency DC/DC conversion, freewheeling diode, and polarity protection applications. It features trench MOS barrier Schottky technology that enables low forward voltage drop and reduced power loss, enhancing overall system efficiency.
The rectifier is packaged in a TO-252 surface mount (DPAK) package with a very low profile of approximately 1.3 mm height, making it ideal for space-constrained electronic designs and automated PCB assembly.
Electrical specifications include a maximum continuous forward current of 10 A, a peak reverse repetitive voltage of 120 V, and a maximum forward voltage drop of 0.62 V. It can withstand peak non-repetitive forward surge current of up to 180 A and operates reliably in temperature conditions ranging from -65°C to 150°C.
The device complies with RoHS standards and has an automotive qualified variant based on the AEC-Q101 standard, reflecting suitability for automotive electronics applications where reliability and robustness are critical.
Applications of this Vishay Schottky barrier rectifier span industrial, automotive, power electronics, and semiconductor device manufacturing sectors. Typical uses include low voltage, high frequency switching power supplies, load dump protection, and reverse polarity protection in electronic circuits.
Equipped with trench MOS barrier technology for high efficiency. Low forward voltage drop of 0.62 V to minimize power losses. Supports peak forward surge current up to 180 A. Operating temperature range from -65°C to 150°C for reliability.
Compact low-profile design with typical height of 1.3 mm. Suitable for high-frequency DC/DC converters and polarity protection. Meets RoHS compliance and automotive qualified base part available. Designed for automated placement in surface-mount assembly processes.
Explore more Vishay Schottky diodes and semiconductors in the EnvMart catalogue for comprehensive electronics component solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 10 A.
This rectifier has a peak reverse repetitive voltage rating of 120 V.
The maximum forward voltage drop is 0.62 V.
It operates reliably within a temperature range of -65°C to 150°C.
This model is packaged in a TO-252 surface mount package.
The typical height of this rectifier is approximately 1.3 mm.
It can withstand a peak non-repetitive forward surge current of up to 180 A.
Yes, it meets RoHS compliance and has an automotive qualified variant based on the AEC-Q101 standard.
It is suitable for low voltage, high frequency DC/DC conversion, freewheeling diode, and polarity protection applications.
This rectifier uses a single diode configuration.
It is equipped with trench MOS barrier technology for high efficiency.
The brand is Vishay and the model is V10PWM12HM3/I.
