Taiwan Semiconductor Bridge Rectifier 100 V 200 A 4-Pin Single Through Hole Package GBU802
Specifications
| Country of Origin | China |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 18.8mm |
| Length | 22.3mm |
| Model | GBU802 |
| Width | 3.56mm |
| Mount Type | Through Hole |
| Series | GBU8 |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | GBU |
| Minimum Operating Temperature | -55°C |
| Number of Phases | 1 |
| Pin Count | 4 |
| Automotive Standard | AEC-Q101 |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200A |
| Forward Current If | 8A |
| Peak Forward Voltage Vf | 1.1V |
| Taiwan Semiconductor Bridge Rectifier, 600 V 200 A, 4-Pin SingleBrand | Taiwan Semiconductor |
Key Features
- Operates within a temperature range of -55°C to 150°C for versatile application.
- Supports peak non-repetitive forward surge current up to 200 A.
- Compact dimensions with length 22.3 mm, width 3.56 mm, and height 18.8 mm.
- Features low peak forward voltage of 1.1 V and peak reverse current of 500 μA for efficient performance.
- Complies with automotive standard AEC-Q101 ensuring robustness for automotive use.
- Single-phase configuration with 4 pins in a GBU package type.
- High case dielectric strength rated at 1500 V RMS enhances durability and safety.
- Ideal for PCB through hole mounting in power and semiconductor circuits.
Product Description
Taiwan Semiconductor GBU802 Bridge Rectifier is a high-quality 4-pin single-phase diode device designed for converting AC to DC with a peak reverse repetitive voltage of 100 V and a maximum forward current of 200 A.
This bridge rectifier supports through hole mounting on printed circuit boards, benefiting industrial, automotive, and electronic component manufacturing applications. It operates reliably in harsh temperature conditions ranging from -55°C to 150°C.
The device features a compact form factor, measuring 22.3 mm in length, 3.56 mm in width, and 18.8 mm in height, which facilitates integration into various electronic assemblies.
High surge current capability up to 200 A peak non-repetitive forward surge current safeguards the circuit during transient events, while low forward voltage drop (1.1 V) and minimal reverse leakage current (500 μA) ensure energy-efficient operation.
Compliant with automotive-grade AEC-Q101 standards, the GBU802 offers robust performance and reliability in automotive electronics and industrial sectors. The package type GBU provides high case dielectric strength of 1500 V RMS, enhancing the device’s resistance to voltage spikes and electrical stress.
Operates at a peak reverse repetitive voltage of 100 V. Maximum forward current rating of 8 A continuous operation. Single-phase 4-pin diode bridge in GBU package. Suitable for PCB through hole mounting. Peak forward voltage of 1.1 V and peak reverse current of 500 μA ensure low power dissipation.
Temperature operating range: -55°C to 150°C. Meets automotive standard AEC-Q101 for enhanced reliability.
This bridge rectifier is essential for power conversion in electronics, industrial machinery, automotive systems, and power supply applications where high surge capability and reliable rectification are required.
Explore more high-performance semiconductor components and Bridge Rectifiers at EnvMart for your industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 150°C.
It has a peak reverse repetitive voltage of 100 V.
The GBU802 supports a peak non-repetitive forward surge current of up to 200 A.
This model measures 22.3 mm in length, 3.56 mm in width, and 18.8 mm in height.
The maximum forward current rating for continuous operation is 8 A.
The GBU802 comes in a GBU package type.
It complies with the automotive standard AEC-Q101.
The peak forward voltage is 1.1 V.
The peak reverse current is rated at 500 μA.
This model is designed for through hole mounting on printed circuit boards.
The minimum operating temperature is -55°C.
The GBU802 is a single-phase bridge rectifier.
