Hirose 0.5 mm Pitch 11 Way Right Angle Female FPC Connector, Bottom Contact FH52-11S-0.5SH
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | 50V ac |
| Brand | Hirose |
| Orientation | Right Angle |
| Current | 500mA |
| Model | FH52-11S-0.5SH |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | 52 |
| Termination Type | Bottom Contact |
| Maximum Operating Temperature | 105°C |
| Sub Type | Easy-On FFC/FPC Connector |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 0.5mm |
| Contact Plating | Gold |
| Number of Contacts | 11 |
| Contact Gender | Female |
| Connector Gender | Female |
| Insertion Force | ZIF |
| Contact Position | Bottom |
Key Features
- Features a low profile mated height of 2 mm for compact PCB integration.
- Equipped with a simple rotating flip lock actuator for easy FPC insertion.
- Metal fittings inside housing provide high retention and actuator stability.
- Two-point contact structure enhances electrical reliability.
- Side catches guide and hold the FPC securely before flip lock engagement.
- Compatible with 0.3 mm standard FPC thickness.
- Solid bottom housing design allows mounting over PCB conductive traces.
- Supports automatic pick-and-place mounting processes.
Product Description
Hirose FH52-11S-0.5SH series 0.5 mm pitch 11 way right angle female FPC Connector features a low profile mated height of 2 mm and a bottom contact termination type. It uses phosphor bronze contacts with gold plating housed in liquid crystal polymer for durability and performance. Designed for surface mount applications, this connector includes a rotating flip lock actuator ensuring easy and secure FPC insertion with tactile lock confirmation.
The connector’s two-point contact structure significantly increases electrical connection reliability, and metal fittings stabilize the actuator for enhanced retention. The side catches guide and temporarily hold the tabbed FPC until locked, preventing disconnection risk. Its robust molded design allows mounting over PCB conductive traces to aid PCB patterning and is fully compatible with standard 0.3 mm thick FPCs.
This product is compliant with halogen-free environmental standards IEC 61249-2-21 and can operate over a temperature range from -40°C up to 105°C. Rated for 50V AC voltage and 500mA current, it suits various industrial and electronic applications.
Ideal use cases include audio and video recording devices, car navigation and audio systems, notebook PCs, portable medical devices, optical drives, industrial control units, satellite receivers, LCD and digital TVs, and printers. This connector supports automated assembly processes such as pick-and-place, facilitating high-volume manufacturing.
Low profile mated height of 2 mm ensures compact PCB design. Rotating flip lock actuator provides easy insertion and secure locking. Metal fittings inside housing increase actuator retention stability. Two-point contact design for enhanced electrical reliability.
Side catches guide and retain tabbed FPC before locking. Solid bottom housing allows mounting over conductive PCB traces. Supports automatic pick-and-place mounting processes. Complies with halogen-free standard IEC 61249-2-21 for environmental safety.
Operates from -40°C to 105°C ensuring durability across harsh environments. Suitable for a wide range of electronics including automotive, medical, industrial, and consumer applications. Explore further options and specifications in EnvMart’s Electronics & Electrical Connectors section for comprehensive solutions tailored to your PCB connectivity requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Hirose FH52-11S-0.5SH connector features a pitch size of 0.5 mm.
This connector can operate at a maximum temperature of 105°C.
The current rating for this model is 500 mA.
It supports surface mounting, making it suitable for compact PCB designs.
The housing is made from liquid crystal polymer, and the contacts are phosphor bronze with gold plating.
This connector is rated for 50V AC voltage.
It has a two-point contact structure that enhances electrical reliability and metal fittings that stabilize the actuator for improved retention.
The minimum operating temperature is -40°C.
The rotating flip lock actuator allows for easy FPC insertion and provides tactile lock confirmation once engaged.
It is suitable for applications such as audio and video devices, car navigation systems, notebook PCs, and portable medical devices.
Yes, it complies with halogen-free environmental standards IEC 61249-2-21.
The connector features female contacts.
