Hirose 0.5 mm Pitch 12 Way Right Angle Female FPC Connector Bottom Contact FH52-12S-0.5SH

Hirose FH52-12S-0.5SH 12 Way Right Angle Female FPC Connector Bottom Contact is engineered for precise and robust connections in compact electronic devices. With a low-profile mated height of 2 mm and a 0.5 mm pitch, this connector is suited for surface mount technology applications requiring high retention force and reliability.

The ZIF (Zero Insertion Force) rotating flip lock actuator simplifies the insertion of the flexible printed circuit (FPC), producing a tactile click when locked, ensuring secure engagement. The contact system uses phosphor bronze contacts plated with gold to maximize conductivity and minimize wear, complemented by a liquid crystal polymer housing for excellent mechanical support.

This connector supports currents up to 500 mA and voltages up to 50 V AC, operating reliably between -40°C to 105°C. The bottom contact termination and right-angle orientation optimize PCB layout and space utilization. A locking mechanism and side catches hold the tabbed FPC securely during operation, with a two-point contact structure enhancing electrical stability.

Compliance with halogen free standards IEC 61249-2-21 ensures it meets environmental safety criteria. Applications suited for the FH52 series include audio-visual equipment, car navigation systems, notebook computers, medical devices, optical disk drives, industrial controls, satellite receivers, LCD and digital TVs, and printers.

Features 12 contacts with 0.5 mm pitch ensuring precise electrical connection. Incorporates easy-to-use rotating flip lock actuator for secure FPC insertion. Constructed with phosphor bronze contacts plated in gold for enhanced conductivity.

Supports surface mount technology with bottom contact termination. Rated for 500 mA current and 50 V AC voltage applications. Operating temperature range from -40°C to 105°C for dependable performance. Employs liquid crystal polymer housing material providing robust mechanical stability.

Designed for bottom contact position with right-angle orientation for space efficiency. Includes locking mechanism and two-point contact design to increase electrical reliability. Halogen free compliant per IEC 61249-2-21 standards for environmental safety.
