onsemi Power P-Channel MOSFET 14 A 60 V Enhancement Mode 8-Pin WDFN Package NVTFS5116PLTAG
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | onsemi |
| Height | 800μm |
| Length | 3.15mm |
| Model | NVTFS5116PLTAG |
| Width | 3.15mm |
| Mount Type | Surface |
| Series | NVTFS5116PL |
| Maximum Operating Temperature | 175°C |
| Package Type | WDFN |
| Minimum Operating Temperature | -55°C |
| Pin Count | 8 |
| Automotive Standard | AEC-Q101 |
| Channel Type | Type P |
| Maximum Continuous Drain Current Id | 14A |
| Maximum Drain Source Voltage Vds | 60V |
| Maximum Drain Source Resistance Rds | 72mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 21W |
| Typical Gate Charge Qg @ Vgs | 25nC |
| Maximum Gate Source Voltage Vgs | 20V |
| Forward Voltage Vf | 1.2V |
Key Features
- Designed for automotive and industrial applications requiring low on-resistance and compact size.
- Enhancement mode MOSFET channel type for efficient switching.
- High maximum power dissipation of 21 watts supports thermal reliability.
- Operates safely in temperatures from -55°C up to 175°C.
- Package dimensions of 3.15 mm length and width facilitate compact PCB design.
- Typical gate charge of 25 nC ensures fast switching performance.
- Complies with automotive standard AEC-Q101 for ruggedness.
- Available with wettable flanks for enhanced optical inspection in manufacturing.
Product Description
onsemi NVTFS5116PLTAG is a power P-Channel MOSFET specifically designed for automotive and industrial applications. It provides a continuous drain current of 14 A and a drain-source voltage rating of 60 V, ensuring high performance and durability.
The device is housed in a compact 8-pin WDFN package measuring 3.15 mm on each side, helping designers to achieve space-efficient layouts. Featuring enhancement mode operation with low drain-source resistance of 72 milliohms, it minimizes conduction losses and improves energy efficiency.
This MOSFET supports a maximum power dissipation of 21 W and can function under a wide temperature range from -55°C to 175°C, making it suitable for harsh environments. It incorporates wettable flanks which enable enhanced optical inspection during automated PCB assembly processes.
Typical gate charge is on the order of 25 nC at gate-source voltage, enabling rapid switching suitable for DC-DC converters, motor drivers, and automotive load switches. This product meets the automotive quality standard AEC-Q101, ensuring reliability and performance in automotive electrical systems.
Designed for automotive and industrial applications requiring low on-resistance and compact size. Enhancement mode MOSFET channel type for efficient switching. High maximum power dissipation of 21 watts supports thermal reliability.
Operates safely in temperatures from -55°C up to 175°C. Package dimensions of 3.15 mm length and width facilitate compact PCB design. Typical gate charge of 25 nC ensures fast switching performance. Complies with automotive standard AEC-Q101 for ruggedness.
Available with wettable flanks for enhanced optical inspection in manufacturing.
Suitable for industrial, automotive, and power management applications including motor drivers and DC-DC switching circuits. This MOSFET delivers reliability and efficiency needed in modern electronic designs.
Explore a wide range of reliable discrete semiconductors and Power MOSFETs in EnvMart’s Electronics & Electricals category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for the NVTFS5116PLTAG is 14 A.
It has a drain-source voltage rating of 60 V.
The typical gate charge is 25 nC at gate-source voltage.
The package dimensions are 3.15 mm in length and 3.15 mm in width.
The maximum power dissipation is 21 W.
It operates safely in temperatures ranging from -55°C to 175°C.
This model complies with the automotive standard AEC-Q101.
It uses a surface mount type.
The maximum drain-source resistance is 72 milliohms.
The pin count for this model is 8.
It is suitable for automotive and industrial applications, including motor drivers and DC-DC switching circuits.
The channel mode is enhancement type.
