Eaton xEffect Miniature Circuit Breaker, 3-Pole, 8A, Type C, 415V ac, 10 kA Breaking Capacity 278868 FAZ-C8/3

Free Delivery in India | Lowest Global Shipping Charges

Eaton xEffect Miniature Circuit Breaker, 3-Pole, 8A, Type C, 415V ac, 10 kA Breaking Capacity 278868 FAZ-C8/3

Name: Eaton xEffect Miniature Circuit Breaker, 3-Pole, 8A, Type C, 415V ac, 10 kA Breaking Capacity 278868 FAZ-C8/3
Brand: Eaton
SKU: 381408
Price: 161.6 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Eaton Condition New

Specifications

Country of Origin	India
Range	xEffect
Brand	Eaton
Model	278868 FAZ-C8/3
Depth	73mm
IP Rating	IP20
Width	85mm
Mount Type	DIN Rail
Current Rating	8A
Series	xEffect
Terminal type	Twin-Purpose Terminal
Breaking Capacity	10kA
Number of Poles	3
Rated AC Voltage	415V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous

Key Features

Designed for control panel applications with DIN rail mounting.
Current limiting design reduces let-through energy during short circuits.
Rated for 8A current with Type C tripping characteristic.
Supports rated AC voltage of 415V AC with 10 kA breaking capacity.
Thermal-magnetic tripping ensures safe and reliable operation.
Toggle switch reset actuator with instant break time.
Red or green contact position indicator enhances operational clarity.
IP20 protection rating suitable for indoor environments.

Product Description

Eaton 278868 FAZ-C8/3 Miniature Circuit Breaker is a high-quality, reliable electrical protection device designed for control panel applications operating at 415V ac. The 3-pole breaker with an 8A current rating provides robust short circuit interruption with a breaking capacity of 10 kA, ensuring protection of electrical circuits from fault currents. The Type C tripping characteristic and thermal-magnetic trip mechanism offer six levels of over-current protection for enhanced safety.

This DIN rail mountable breaker from the xEffect series features a toggle switch reset actuator and instant break performance. The breaker’s current limiting design reduces damaging let-through energy during short circuits, prolonging equipment life and improving system safety. The toggle can be sealed in both ON and OFF positions for secure operation, and the trip-free design prevents holding the handle ON to defeat safety trips.

The unit includes twin-purpose terminals for secure connections and has an IP20 rating, suitable for indoor electrical environments. Compactly designed with 85mm width and 73mm depth dimensions, it fits efficiently within control panels. Red and green lights visually indicate contact position, improving usability and maintenance.

The Eaton FAZ series is widely trusted for reliable circuit protection, suitable for industrial, commercial, manufacturing, and HVAC electrical systems as supplementary protection.

Reliable 3-pole miniature circuit breaker with 8A current rating and Type C tripping. Rated voltage of 415V AC and breaking capacity of 10 kA ensures safe interruption. Thermal-magnetic tripping mechanism provides sensitive and reliable protection.

DIN rail mountable design with compact dimensions ideal for panel installation. Toggle switch actuator with instant break time and sealed ON/OFF positions. IP20 protection rating suitable for indoor electrical environments.

Twin-purpose terminals for easy wiring and connection flexibility. Red/green contact position lights improve visibility and operational feedback. Ideal for supplementary protection across industrial and commercial electrical systems.

Explore the Eaton range for high-quality Miniature Circuit Breakers and electrical protection products on EnvMart.
