Molex Nano-Fit Series Straight Through Hole PCB Header, 4 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 105309-1104

Molex 105309-1104 Nano-Fit Series Straight Through Hole PCB Header is a high-performance wire-to-board connector designed for compact PCB applications. This model features 4 male contacts arranged in a single row with a 2.5 mm pitch, providing reliable electrical connections and easy integration in tight spaces.

Constructed from brass contact material with tin plating, it provides excellent corrosion resistance and durability. The shrouded housing prevents damage to contacts and facilitates secure mating, reducing connector failures and ensuring system integrity.

Rated for 6.5A current and 250V operating voltage, the header is well-suited for industrial, commercial, and electronic equipment applications subjected to varying temperatures ranging from -40°C to 105°C. The solder tail termination with a pin length of 3.2 mm enables easy through-hole mounting on PCBs, often used in manufacturing and assembly processes.

Key benefits include a positive-lock housing with an anti-snag design to prevent accidental disconnection, fully isolated terminals enabling multi-layer PCB usage, and terminals with four-point contact for enhanced electrical performance.

This PCB header is supplied with embossed tape packaging for efficient automated assembly lines and meets no specific certifications but adheres to industry standard mechanical and electrical specifications.

Compact, fully isolated Nano-Fit PCB header minimizes space consumption. 6.5A current rating supports reliable power and signal transmission. Durable brass contacts with tin plating resist corrosion and wear. Shrouded housing protects contacts and ensures secure mating.

Positive-lock housing with anti-snag design enhances connection reliability. Through-hole mount compatible with standard PCB soldering techniques. Wide operating temperature range from -40°C to 105°C for diverse environments.

Available in embossed tape format for seamless automated assembly.

This Molex Nano-Fit PCB header is ideal for electronic, industrial, laboratory, manufacturing, and commercial applications requiring compact, reliable wire-to-board connections. Explore more PCB connectors and components at EnvMart to find tailored solutions for your design needs.
