DiodesZetex Small Signal NPN Transistor 600 mA, 40 V, 3-Pin SOT-23 Package MMBT2222A-7-F

DiodesZetex MMBT2222A-7-F is a high-quality small signal NPN transistor designed for discrete semiconductor applications requiring reliable switching and amplification. It features a maximum DC collector current of 600 mA and can handle collector-emitter voltages up to 40 V. Packaged in a compact 3-pin SOT-23 surface mount package, it supports efficient PCB layout in space-constrained designs.

This transistor dissipates up to 300 mW of power and operates effectively within an extended temperature range of -55°C to 150°C, making it suitable for demanding industrial and automotive environments. The device ensures good current gain with hFE of at least 35, enabling stable transistor operation in signal amplification tasks.

The product is compliant with the AEC-Q101 automotive standard, signifying its robustness and reliability for automotive electronics and other high-performance applications. Its small size - 3 mm length, 2.5 mm width, and 1.1 mm height - facilitates dense mounting on printed circuit boards.

Applications include industrial electronics, automotive control systems, communication equipment, and general electronic signal amplification or switching tasks. Supports a maximum DC collector current of 600 mA. Maximum collector-emitter voltage rating of 40 V ensures reliable switching.

Equipped with 3 pins in a compact SOT-23 surface mount package. Maximum power dissipation is 300 mW for efficient thermal management. Wide operating temperature range from -55°C to 150°C for harsh environments. Transistor polarity is NPN, suitable for switching and amplification.

Minimum DC current gain (hFE) is 35 ensuring good amplification. Compliant with automotive standard AEC-Q101 for industry quality assurance. Dimensions: length 3 mm, width 2.5 mm, height 1.1 mm for space-saving PCB design.

Single transistor configuration suited for discrete semiconductor applications.

This transistor is ideal for use in industrial control systems, automotive electronics, communication devices, and other electronics manufacturing requiring reliable small-signal transistors. Explore more semiconductor solutions in the Bipolar Transistors category at EnvMart.
