Vishay 600 V 8 A Switching Diode Single 3-Pin DPAK Surface Mount TO-252 Package VS-8EWF06S-M3

Free Delivery in India | Lowest Global Shipping Charges

Vishay 600 V 8 A Switching Diode Single 3-Pin DPAK Surface Mount TO-252 Package VS-8EWF06S-M3

Name: Vishay 600 V 8 A Switching Diode Single 3-Pin DPAK Surface Mount TO-252 Package VS-8EWF06S-M3
Brand: Vishay
SKU: 217670
Price: 20.22 USD
Availability: InStock



Category Semiconductors Brand Vishay Condition New

Specifications

Country of Origin	India
Diameter	2.39mm
Brand	Vishay
Height	2.39mm
Length	6.73mm
Model	VS-8EWF06S-M3
Width	6.22mm
Mount Type	Surface
Series	VSX
Maximum Operating Temperature	150°C
Package Type	TO-252
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Continuous Forward Current If	8A
Peak Reverse Repetitive Voltage Vrrm	600V
Diode Configuration	Single
Rectifier Type	Switching
Peak Reverse Current Ir	100μA
Peak Non-Repetitive Forward Surge Current Ifsm	200A
Maximum Forward Voltage Vf	1.2V
Peak Reverse Recovery Time trr	140ns

Key Features

Surface mount device with TO-252 (DPAK) package for compact PCB integration.
Maximum continuous forward current of 8 amperes ensures reliable performance.
Peak reverse repetitive voltage rated at 600 volts.
Fast recovery switching diode with a peak reverse recovery time of 140 nanoseconds.
Operates in a temperature range from -40°C to 150°C for diverse industrial environments.
Single diode configuration with 3 pins designed for efficient heat dissipation.
Maximum forward voltage drop of 1.2 volts to optimize power efficiency.
RoHS compliant ensuring environmental standards compliance.

Product Description

Vishay VS-8EWF06S-M3 is a high-efficiency switching diode designed for surface mount technology applications in electronic devices. Featuring a TO-252 (DPAK) package with three pins, this diode supports a maximum continuous forward current of 8 A and withstands peak reverse voltages up to 600 V. It is engineered to provide fast recovery switching characteristics with a peak reverse recovery time of 140 ns, suitable for high-speed circuit operations.

The diode operates reliably in harsh industrial environments from -40°C up to 150°C, making it ideal for power management in applications such as power supplies, automotive electronics, and industrial controls. Its compact TO-252 footprint allows for efficient PCB layout and heat dissipation, enhancing longevity and performance stability.

Single diode configuration ensures straightforward integration into circuits requiring precise diode functionality. The maximum forward voltage of 1.2 V contributes to reduced power losses and improved electrical efficiency. Vishay VS-8EWF06S-M3 complies with RoHS standards, supporting environmentally conscious design practices.

Surface mount TO-252 (DPAK) package for compact layout and thermal management. Maximum continuous forward current of 8 A supports demanding power applications. Peak reverse voltage of 600 V ensures wide application versatility.

Fast recovery time of 140 nanoseconds enables rapid switching performance. Operational temperature range from -40°C to 150°C for robust industrial use. Low forward voltage drop of 1.2 V minimizes energy loss in circuits.

RoHS compliant for environmental safety and regulatory compliance.

Vishay’s VS-8EWF06S-M3 diode is an excellent choice for industrial, automotive, power management, and electronic design applications requiring reliable and efficient switching diode performance. Explore more Vishay semiconductor components for your projects on EnvMart.
