DiodesZetex 150 V 1 A General Purpose Schottky Barrier Diode 2-Pin DO-214AC SBR1U150SA-13

DiodesZetex SBR1U150SA-13 is a high-performance general purpose Schottky barrier diode featuring a low forward voltage drop and surface mount DO-214AC package. Rated for a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 150 volts, this diode is ideal for reliable rectification in electronic circuits requiring efficient power conversion.

The device operates effectively within a wide temperature range from -65°C to 150°C, making it suitable for demanding industrial, automotive, and electronic applications. Its compact dimensions (height 2.3 mm, length 4.6 mm, width 2.92 mm) facilitate high-density PCB layouts and surface mounting assembly processes.

With a peak non-repetitive forward surge current of 42 amperes, the SBR1U150SA-13 diode withstands transient surge conditions while maintaining stability. The diode conforms to automotive AEC standards, providing enhanced reliability for automotive and industrial markets.

This 2-pin, single diode configuration is commonly used in power supplies, protection circuits, and signal rectification tasks, benefiting from the low forward voltage (700 mV) to minimize power dissipation and improve overall efficiency.

Schottky barrier rectifiers offer superior switching speed and reduced power loss compared to traditional PN junction diodes, making this diode a versatile choice for modern electronics and power management systems.

Maximum continuous forward current of 1 ampere ensures reliable operation in various circuits. Peak reverse repetitive voltage of 150 volts suitable for moderate voltage applications. Low maximum forward voltage of 700 mV reduces power losses and improves efficiency.

Wide operating temperature range from -65°C to 150°C supports demanding thermal environments. Compact DO-214AC surface mount package with dimensions: height 2.3 mm, length 4.6 mm, width 2.92 mm. Peak non-repetitive forward surge current of 42 amperes for transient load tolerance.

Automotive grade AEC standard compliance ensures high quality and reliability. 2-pin single diode configuration for easy circuit integration and rectification tasks. General purpose rectifier suitable for power supply, signal processing and protection circuits.

Suited for industrial, automotive, electronic component manufacturing, and power supply design applications, the SBR1U150SA-13 diode represents a dependable choice for enhancing circuit performance. For more high-quality diodes and electronic components, explore our Semiconductor and Diodes categories on EnvMart.
