DiodesZetex 40 V 1.1 A Schottky Diode 2-Pin Surface Mount PowerDI123 DFLS140-7

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 40 V 1.1 A Schottky Diode 2-Pin Surface Mount PowerDI123 DFLS140-7

Name: DiodesZetex 40 V 1.1 A Schottky Diode 2-Pin Surface Mount PowerDI123 DFLS140-7
Brand: DiodesZetex
SKU: 217464
Price: 0.27 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	1mm
Length	3mm
Model	DFLS140-7
Width	1.93mm
Mount Type	Surface
Series	DFLS140
Maximum Operating Temperature	125°C
Package Type	PowerDI123
Minimum Operating Temperature	-55°C
Standards/Approvals	FBI
Pin Count	2
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	1.1A
Peak Reverse Repetitive Voltage Vrrm	40V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	6mA
Peak Non-Repetitive Forward Surge Current Ifsm	40A
Maximum Forward Voltage Vf	510mV

Key Features

This surface mount Schottky diode features a PowerDI123 package for compact PCB integration.
It has a maximum continuous forward current of 1.1 amperes to handle moderate current loads.
The diode exhibits a low forward voltage drop of 510 millivolts for energy-efficient performance.
Operating temperature ranges from -55°C to 125°C enable use in harsh environments.
It provides a peak reverse repetitive voltage rating of 40 volts ensuring robust voltage blocking capability.
The device is qualified to automotive standard AEC-Q101, confirming reliability in automotive applications.
Its 2-pin configuration simplifies circuit design and mounting on printed circuit boards.
With dimensions of 3 mm length, 1.93 mm width, and 1 mm height, it is suitable for space-constrained designs.

Product Description

DiodesZetex DFLS140-7 is a 2-pin Schottky diode designed for surface mount applications. Featuring a PowerDI123 package, this diode offers a maximum continuous forward current of 1.1 A and a peak reverse repetitive voltage of 40 V, making it ideal for efficient rectification in power and signal circuits.

Its low forward voltage drop of 510 mV enhances circuit efficiency by minimizing power loss. The diode supports a wide operating temperature range from -55°C up to 125°C, ensuring reliable function in harsh industrial and automotive environments. Meeting the automotive AEC-Q101 standard, the DFLS140-7 suits demanding automotive electronic applications requiring high reliability and thermal stability.

Compact dimensions of 3 mm length, 1.93 mm width, and 1 mm height facilitate integration on densely populated printed circuit boards. The 2-pin configuration and surface mount package type simplify automated assembly, enhancing production efficiency in mass manufacturing.

The Schottky barrier diode technology employed provides minimal forward voltage and fast switching capabilities, beneficial for power supply circuits, voltage clamping, and polarity protection designs in industrial, automotive, and electronic manufacturing sectors.

This diode is surface mount type with PowerDI123 package for space-saving PCB layouts. It supports continuous forward current of 1.1 A, suitable for moderate load applications. Peak reverse voltage rating is 40 V, ensuring effective voltage blocking.

Low forward voltage of 510 mV reduces conduction losses and heats generation. The device complies with AEC-Q101 automotive reliability standard. Operating temperature range extends from -55°C to 125°C supporting diverse environments.

Dimensions are compact at 3 x 1.93 x 1 mm (LxWxH). Designed for industrial, automotive, and electronic component applications requiring durable diode performance. Explore our vast range of semiconductor components at EnvMart for your electronic design and manufacturing needs.
