Samtec IPL1 Series Straight Through Hole PCB Header, 4 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1

Free Delivery in India | Lowest Global Shipping Charges

Samtec IPL1 Series Straight Through Hole PCB Header, 4 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1

Name: Samtec IPL1 Series Straight Through Hole PCB Header, 4 Contacts, 2.54 mm Pitch, 2 Row, Shrouded IPL1
Brand: Samtec
SKU: 216027
Price: 2.65 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	United States
Voltage	954V
Brand	Samtec
Orientation	Straight
Current	3.8A
Model	IPL1
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	IPL1
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Features a pitch of 2.54 mm for standard PCB spacing.
Incorporates 4 gold-plated phosphor bronze contacts for corrosion resistance.
Housing made of liquid crystal polymer ensures high temperature operation.
Shrouded design protects contacts and prevents misalignment.
Rated for 3.8A current capacity at 95°C operating temperature.
Supports through-hole mounting for sturdy PCB attachment.
Operates within temperature range from -55°C to 125°C.
Designed with straight orientation and two rows for compact layout.

Product Description

Samtec IPL1 Series Straight Through Hole PCB Header IPL1 is engineered for reliable wire-to-board connections in electronic assemblies. This connector features a pitch of 2.54 mm and houses 4 male contacts arranged in 2 rows, designed to fit precisely on PCBs with standard spacing. The contacts are made from phosphor bronze and plated with gold to ensure long-lasting conductivity and resistance to corrosion.

The housing utilizes liquid crystal polymer, enabling the component to withstand high temperatures up to 125°C while maintaining structural integrity. The shrouded design safeguards the contacts from damage and misalignment during insertion, enhancing connection reliability.

This PCB Header supports through-hole mounting technology, offering robust mechanical stability for demanding industrial and commercial electronics use. Rated for a current capacity of 3.8 amperes at 95°C, it can handle substantial electrical loads safely. Its operational temperature range from -55°C to 125°C suits applications in harsh or varied environments.

The connector is rated for a maximum voltage of 954 volts, providing high insulation and protection in electronic circuits. Its standard straight orientation and double row configuration make it ideal for compact and efficient PCB designs in diverse fields such as industrial equipment, instrumentation, automation, and consumer electronics.

Pitch: 2.54 mm spacing between pins. Number of contacts: 4 gold-plated phosphor bronze pins. Housing material: durable liquid crystal polymer for thermal and mechanical stability. Shrouded design for protection and alignment.

Current rating: 3.8A at 95°C. Mounting type: through hole for secure PCB attachment. Operating temperature: -55°C to 125°C. Voltage rating: 954V maximum. Orientation: straight with two rows.

This product is manufactured in the United States by Samtec, ensuring high-quality production standards and consistent performance. It is suitable for industrial, laboratory, manufacturing, and electronics development applications requiring reliable PCB connectivity.

Discover this and other high-performance connectors at EnvMart to upgrade your design or manufacturing needs with trusted components from Samtec.
