Molex 10-Way IDC Connector Female for Surface Mount, 1 Row, 1.27mm Pitch, 250V AC, 1.2A Current, Picoflex Series 90816-0010

Molex 90816-0010 10-Way IDC Connector Female for Surface Mount, 1 Row, 1.27mm pitch, is a precision connector engineered for robust wire-to-board connections. It supports a voltage of 250V AC and a current rating of 1.2A, making it suitable for various industrial and commercial electronic devices.

This IDC connector features ten female brass contacts with tin plating for excellent conductivity and corrosion resistance. The connector housing is made of polyphthalamide, which offers high strength and thermal stability, compatible with harsh operating environments ranging from -40°C to 105°C.

The unshrouded, straight orientation connector is equipped with a positive latch that ensures secure mating and increased retention on the PCB surface. Its surface mount design and 1.27mm pitch provide excellent density saving approximately 50% space compared to traditional connectors, with a compact mated height of only 6.4mm.

This product is part of the Molex Picoflex series, renowned for their low profile, vibration resistance, and excellent polarisation features, commonly adopted in automotive and consumer electronics industries.

10 female contacts in one row for efficient wire-to-board connection. Solder termination type ensures reliable attachment to PCB. Positive latch and polarized side posts for secure assembly. Housing material offers excellent mechanical and thermal performance.

Suitable for high-density applications requiring space savings. Supports operating temperatures from -40°C to 105°C. Unshrouded design facilitates easy inspection and maintenance. Supports surface mounting on PCBs for compact layout.

Perfect for industrial, automotive, and consumer electronic devices. Origin: Ireland. Explore more IDC Connectors and related products to suit your electronics assembly needs on EnvMart.
