Hirose DF11 Series 4 Contact Straight Through Hole Shrouded PCB Header 2 mm Pitch 2 Row DF11
Specifications
| Country of Origin | Malaysia |
|---|---|
| Voltage | 250V |
| Brand | Hirose |
| Orientation | Straight |
| Current | 2A |
| Model | DF11 |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | DF11 |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -30°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Hirose, DF11, 4 Way, 2 Row, Straight PCB HeaderBrand | Hirose |
Key Features
- Compact double row design with 4 contacts and 2 mm pitch.
- Shrouded housing made of durable polyamide material.
- Supports up to 2A current with 250V voltage rating.
- Through hole mount type ensuring reliable PCB retention.
- Features copper alloy contacts with tin plating for corrosion resistance.
- Operates between -30°C to 85°C for versatile environmental use.
- Integrated guide ribs prevent incorrect insertion and twisting.
- Locking mechanism ensures secure mating connection.
Product Description
Hirose DF11 model DF11 is a high-quality PCB header connector featuring 4 contacts arranged in 2 rows with a 2 mm pitch. It is designed as a straight, shrouded through hole element ensuring robust mechanical and electrical connections on printed circuit boards.
The housing is made from polyamide material providing durability and insulation, while the copper alloy contacts plated with tin ensure reliable conductivity and resistance to corrosion. Rated for 2 amps current at 250 volts, this connector operates reliably across a wide temperature range from -30°C to 85°C.
The compact double row design saves space on PCB assemblies by fitting double rows of contacts in the footprint of a single row. Guide ribs and a locking mechanism prevent incorrect insertion and secure the mating connection. The through hole mount type contributes to strong PCB retention, with metal fittings on SMT variants enhancing stability and preventing solder peeling.
This connector system supports both board-to-board and wire-to-board applications, making it versatile for various electronic designs including digital cameras, LCD displays, digital video recorders, car navigation units, access control, and measurement devices.
Manufactured in Malaysia, the DF11 Series PCB header by Hirose ensures high performance and reliability in compact electronic devices. Compact double row design with 4 contacts and 2 mm pitch. Shrouded polyamide housing for durability and insulation.
Copper alloy contacts with tin plating resist corrosion. Rated for 2A current and 250V voltage. Operational temperature range from -30°C to 85°C. Guide ribs and locking mechanism prevent misalignment. Through hole mount ensures PCB retention.
Supports board-to-board and wire-to-board connection schemes. Ideal for use in compact portable electronic devices. Manufactured in Malaysia with quality assurance. Explore a wide range of PCB Headers and connectors in the Electronics & Electricals category at EnvMart for reliable industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 2A and a voltage of 250V.
It operates reliably within a temperature range of -30°C to 85°C.
The housing is made of polyamide, while the contacts are composed of copper alloy with tin plating for corrosion resistance.
It features 4 contacts arranged in 2 rows with a 2 mm pitch.
This connector uses a through hole mount type, ensuring strong PCB retention.
It supports both board-to-board and wire-to-board connection schemes.
Yes, it includes integrated guide ribs and a locking mechanism to prevent incorrect insertion and ensure a secure connection.
The orientation of this connector is straight.
It is manufactured in Malaysia.
The termination type for this model is solder.
The contact gender for this connector is male.
This PCB header is suitable for various electronic designs, including digital cameras, LCD displays, digital video recorders, and car navigation units.
